Small Fully Automatic SF6 Recovery Device, Oil-free Compressor, Vacuum Recovery, 300L Storage Tank
As a drafting unit for the industry standard "DL/T1353 - 2024 Technical Specification for Sulfur Hexafluoride Treatment System" issued by the National Energy Administration of China, our company specializes in customized SF6 recovery devices. These devices are classified by functions such as recycling, vacuuming, and inflation, with configurations tailored to customer needs—including negative pressure recycling, oil - free compressors, compressor speed, liquid storage tank capacity, freezing functions, moisture/particle filtration, and full - automation. Below is an introduction to a compact fully automatic recycling device featuring negative pressure recovery, oil - free operation, and integrated suction - inflation capabilities (Model: KSLH - 6WY20 - 54 - 300Z), equipped with a 6m³/h oil - free high - pressure compressor, 20m³/h negative pressure compressor, 54m³/h vacuum pump, 300L storage tank, and fully automated operation.
1. Device Performance Parameters
| Parameter | Description |
|---|---|
| Type | High - pressure liquefaction, air - cooled, hand - push mobile |
| Ambient Temperature | -10℃～40℃ |
| Recycling | Initial pressure: ≤30 bar Final pressure: ≤-0.09 MPa |
| Inflation | Initial pressure: ≤133 bar Final pressure: ≤10 MPa |
| Ultimate Vacuum | ≤5 Pa |
| Annual Leakage Rate | ≤0.5% |
| Recycled SF6 Gas Purity | Moisture content: ≤60 (PPM/V) Oil content: 0 (PPM/G) |
| Storage Container | Storage method: Liquid Pressure: 39 bar Volume: 350 L Liquid storage capacity: 350 kg Liquefaction method: High - pressure liquefaction |
| Dry Filter Regeneration | Vacuum heating activation regeneration |
| Power Supply | 3Φ 380V 50HZ |
| Total Power | ≤7 (kW) |
| Noise Level | ≤75 A (dB) |
| Equipment Weight | ≤1000 kg |
2. Main Component Performance Parameters
| Component | Parameter | Value |
|---|---|---|
| SF6 Compressor | Form | Air - cooled piston |
| Theoretical Displacement | 6 m³/h | |
| Maximum Exhaust Pressure | 50 bar | |
| Allowable Exhaust Pressure | 47 bar | |
| Minimum Suction Pressure | -5 mbar | |
| Maximum Suction Pressure | 3 bar | |
| Maximum Exhaust Temperature | 130℃ | |
| Lubricant | None | |
| Power | 2.2 kW | |
| Vacuum Pump | Pumping Speed | 63 m³/h |
| Ultimate Pressure | ≤0.1 mbar | |
| Power | 2.2 kW | |
| Storage Container | Category | TYPE TWO |
| Design Pressure | 39 bar | |
| Design Temperature | 100℃ | |
| Capacity | 350 L | |
| Liquid Storage Capacity | 350 kg |
Working voltage, storage tank size, etc. are optional.
