ISO 817 Burning Rate Tester Various Flammable Gases Combustion Characteristics Testing Machine Flame Propagation Speed Tester
ISO 817 Burning Rate Tester Various Flammable Gases Combustion Characteristics Testing Machine Flame Propagation Speed Tester
Product Description
Testing combustion characteristics of various flammable gases in vertical pipes including flame propagation speed and burning rate, compliant with GB/T 12474, ISO 817, ASHRAE NA-04-1-3-2004, etc.
CISO 817 Burning Rate Tester Various Flammable Gases Combustion Characteristics Testing Machine Flame Propagation Speed Tester
Technical Specification
Measurement Object | Flammable gases |
Measurement Range | 3 cm/s < combustion speed ≤ 40 cm/s |
Temperature Range | RT |
Pressure Range | Atmospheric pressure |
Measurement Basis | Flame propagation |
Ignition Conditions | 15 kV, 30 mA |
Gas Distribution Accuracy | 0.1% |
Pressure Sensor Accuracy | 0.1% FS |
Working Environment | 0~40 °C, ≤ 65% RH |
Power Supply | 220 V, 50 Hz |
