Product Introduction
The petroleum product density tester is designed and manufactured in accordance with the requirements of GB/T 1884,ASTM D1298. It adopts a high-performance microprocessor, a color touch liquid crystal display, and PID self-tuning control technology. It has the advantages of high temperature control accuracy, reliable performance, and convenient operation. It uses the density meter method to measure the density of liquid petroleum products at a certain constant temperature. It is mainly used for low-viscosity liquids and viscous liquids. It is widely used in the fields of petroleum, chemical industry, power, commodity inspection, universities, research, etc.
Functional Features
1. Color LCD touch screen, with intuitive and convenient operation
2. Utilizing PID automatic temperature control technology, the temperature control accuracy is very high.
3. Optional immersion cooler can be used for low-temperature density measurement
4. The instrument is equipped with a high-performance microprocessor, which is highly responsive and has stable performance.
5. Chinese/English interface display (optional)
ASTM D1298 Petroleum Product Density Tester Color LCD Touch Screen Liquid Petroleum Products Density Meter Oils Densimeter
Technical Specification
|
Applicable Standards |
GB/T1884,ASTM D1298 |
|
Operation Display |
Color LCD touch screen |
|
Temperature Control Range |
0℃ to 100℃ (a cooler is required for the temperature range of 0℃ to room temperature) |
|
Measurement Range |
0.600g/cm³ to 2.000g/cm³ (density meter is optional) |
|
Resolution |
0.01 degree Celsius |
|
Cold Bath Medium |
Water bath, oil bath and ethanol bath can be chosen at will |
|
Temperature Control Accuracy |
±0.05℃ |
|
Heating Power |
≤1500W |
|
Number of Experimental Holes |
Two holes |
|
Density Meter |
Ten pieces |
|
Environmental Temperature |
5℃ to 45℃ |
|
Relative Humidity |
10% to 80% Rh |
|
Power Supply Voltage |
220V±10% 50HZ |
|
Dimensions of the Shape |
528×380×486mm |
|
Instrument Weight |
20.20 kilograms |
