Cotton Fancy Yarn Spinning Machine Laboratory Fancy Cotton Spinning Frame Small-scale Spinning Machine
Cotton Fancy Yarn Spinning Machine Laboratory Fancy Cotton Spinning Frame Small-scale Spinning Machine
Application Scope
This equipment is equipped with a core yarn roller, and the front, middle, and rear rollers are independently driven. With two sets of roving feeding, it can produce fancy yarns with varying colors and structures by changing the drafting ratio and yarn twist.
Features
This machine is one of the small-scale spinning machines in the series. It has a small footprint, simple operation and adjustment, and is suitable for rapid spinning trials with small amounts of raw materials. It is ideal for schools, research institutions, and R&D centers.
Cotton Fancy Yarn Spinning Machine Laboratory Fancy Cotton Spinning Frame Small-scale Spinning Machine
Technical Specification
|
Control Method |
Touch screen + PLC |
|
Number of Spindles |
4/6 |
|
Twist Range |
Approx. 200-2000 twists/m |
|
Drafting Range |
Approx. 2-50 |
|
Fiber Length |
22 to 42 mm |
|
Production Capacity |
Approx. 0.25-0.5 kg |
|
Ring Spindle Speed |
12000 rpm |
|
Roller Size |
Φ25/25/25 mm |
|
Ring Size |
Φ42 mm |
|
Total Power |
1500 W |
|
Voltage |
220/3*380V AC 50/60Hz |
|
Dimensions |
1.2 m * 0.8 m * 1.6 m |
