Gas-Liquid Ratio Burst Test Bench Laboratory Gas-Liquid Ratio Pressure Burst Test Stand Petroleum Tester Petroleum Petro
Gas-Liquid Ratio Burst Test Bench Laboratory Gas-Liquid Ratio Pressure Burst Test Stand Petroleum Tester Petroleum Petro
Gas-Liquid Ratio Burst Test Bench Laboratory Gas-Liquid Ratio Pressure Burst Test Stand Factory Price
Applicable Products
Radiators, condensers, evaporators, intercoolers, heater cores, oil coolers, heaters, pressure gauges, fire-fighting equipment, metal connectors, valves, hose assemblies, pipelines, pressure vessels, pressure transmitters, etc.
Test Procedures
1. Constant rate pressure increase - burst
2. Constant rate pressure increase - pressure holding - burst
3. Constant rate pressure increase - pressure holding - pressure release
4. Constant rate pressure increase - pressure holding - pressure release - constant rate pressure increase - burst
5. Incremental pressure increase
End Gas-Liquid Ratio Burst Test Bench Laboratory Gas-Liquid Ratio Pressure Burst Test Stand Factory Price
Technical Specification
|
Pressure Range |
0~500MPa (range can be selected as needed) |
|
Pressure Increase Rate |
3~300MPa/min, adjustable |
|
Test Specimen Diameter |
Φ3-Φ150mm |
|
Test Specimen Length |
100-1000mm |
|
Ambient Temperature |
-60-180℃ (optional) |
|
Medium Temperature |
RT-180℃ (optional) |
|
Test Medium |
Water, water-ethylene glycol, hydraulic oil |
|
Number of Test Specimens |
1 piece |
|
Optional features |
Elongation, expansion rate, oscillation, torsion |
