LONROY Laser Power Meter Digital Display Thermoelectric Laser Power Meter Laser Power Sensor Head Laser Power Measuring Probe
LONROY Laser Power Meter Digital Display Thermoelectric Type Laser Power Meter Laser Power Sensor Head Laser Power Measuring Probe
Product Overview
LR-M100 is a professional version universal probe head. It is compatible with all types of laser power meter probes, including photoelectric, integrated, industrial, and portable ones. It features "digital display", "data statistics", and "data storage" functions. It can be connected to a PC via USB, and the user-end software can be configured to support data acquisition and export.
Characteristics
The accuracy is as high as ±0.25%.
Electromagnetic interference shielding
Single-pulse energy testing
Statistical and averaging functions, long-term stability testing
It can store 250,000 measurement data.
It can be connected to a PC via USB, and the user-end software can be configured. It supports data collection and export.
LONROY Laser Power Meter Digital Display Thermopile Type Laser Power Meter Laser Power Sensor Head Laser Power Measuring Probe
Laser Power Meter Parameters
|
Model |
LR-M100 |
|
Digital display |
√ |
|
Data statistic |
√ |
|
Data storage |
√ |
|
Connecting to PC via USB |
√ |
|
PC software |
√ |
|
Data acquisiting and exporting |
√ |
|
Single pulse energy testing |
√ |
|
Display format |
Numerical,Columnar graph,Chart |
|
Accuracy (±%) |
0.25 |
|
Display type |
240(RGB) × 320 pixels , TFT-LCD |
|
Display dimensions |
65.0mm x 48.8mm(2.56" x 1.92") |
|
ADC sampling frequency |
20 Hz |
|
AD converter |
24 bit |
|
Connector type |
DB-9F |
|
Digital interface |
USB 2.0 |
|
Battery |
Li-Polymer, 3.7 V,4050 mAh |
|
Battery life |
> 40 h |
|
Charger / DC input |
5 V / 2 A |
|
Dimensions(L x W x H) |
165mm x 108mm x 25mm |
|
Weight |
< 0.25 kg |
|
Operating temperature |
0 to 40 °C |
|
Storage temperature |
-10 to 45 °C |
