4.2m New Energy Vehicle Refrigeration Freezing Unit DC Frequency Conversion CAN Bus Control IPC3 Standard Remote Monitoring
Price:
USD 3000~15000/unit
MOQ:
10
Delivery Time:
30 days
Brand:
Newbase
Product Description
4.2m New Energy Vehicle Refrigeration Freezing Unit DC Frequency Conversion CAN Bus Control IPC3 Standard Remote Monitoring
Product Attributes
| Attribute | Value |
|---|---|
| Quality | 100% Tested |
| Warranty | 18M |
| Refrigerant Type | R-404A |
| Engine | 1.4 i |
| Defrost Type | Hot Gas |
| Year | 1998- |
| Purpose | for replace/repair |
| Reference No | NEWBASE |
| Car Model | Truck |
| Condition | New |
Refrigeration and Freezing Unit for 4.2m New Energy Vehicles
Designed for 15-25m³ cargo compartments, this unit combines advanced technology for efficient temperature control in new energy vehicles.
Key Features
- Full DC Frequency Conversion: Enables rapid cooling and low-power consumption during low-frequency insulation.
- Stepless Cooling Adjustment: Maintains temperature accuracy and stability within -25℃ to +30℃.
- Multi-sensor Monitoring: Built-in pressure and temperature sensors for real-time detection and automatic operation adjustment.
- Rigorous Testing: Validated through vibration, rain exposure, insulation, and EMC Level III tests for reliability.
- CAN Bus Control: Based on CAN2.0B and SAE J1939 for seamless vehicle integration.
- IPC3-Grade Electronics: Ensures high-performance electronic components production.
- Cloud Platform Management: Remote monitoring via IoT for real-time temperature data and fault diagnosis.
- Big Data Analysis: Proactive fault warning and remote diagnostics for minimized downtime.
Product Parameters
| Model | NBSRE520 |
|---|---|
| Applicable Volume | 15-25m³ |
| Temperature Range | -25℃ ~ +30℃ |
| Cooling Capacity | 5200W at 0℃/30℃ 2800W at -20℃/30℃ |
| High Voltage | Low Voltage: DC250V-DC450V High Voltage: DC380V-DC750V |
| Power Consumption | 2850W at 0℃/+30℃ 2430W at -20℃/+30℃ |
| Driven Mode | Full Electric |
| Control Voltage | DC12V (9~16V)/DC24V (16~32V) |
| Standby Power (Optional) | AC220V/380V |
| Compressor | DTH356 (Variable Frequency) |
| Refrigerant | R404A, 2.3kg Filling |
| Defrosting/Heating Mode | Hot Gas |
| Condenser Unit | Size: 1633*485*485mm Weight: 82kg |
| Condenser Fan | 2 pcs, 4000m³/h Air Volume |
| Evaporator Unit | Size: 1092*590*241mm Weight: 24kg |
| Evaporator Fan | 2 pcs, 2000 m³/h Air Volume |
Real-world Applications
Ideal for new energy delivery trucks, this unit ensures precise temperature control for:
- Fresh Food Transport: Maintains perishables like fruits, vegetables, and dairy at optimal temperatures.
- Pharmaceutical Logistics: Supports cold chain storage for vaccines, medicines, and biological products.
- Frozen Goods Delivery: Enables reliable freezing for meats, seafood, and ice cream at -25℃.
The unit's low-power DC operation aligns with new energy vehicle efficiency standards, reducing carbon footprint while ensuring consistent performance.
