China AA10VSO45DFR1/31R-PPA12N00 A10VSO71DRG/31R-PPA12N00 L10VSO100DFLR/31R-PPA12N00 HA10VSO45DR/31R-PPA12N00 L10VSO45DFR1/31R-PPA12N00German Rexroth Mechanical System Piston Pump for sale

AA10VSO45DFR1/31R-PPA12N00 A10VSO71DRG/31R-PPA12N00 L10VSO100DFLR/31R-PPA12N00 HA10VSO45DR/31R-PPA12N00 L10VSO45DFR1/31R-PPA12N00German Rexroth Mechanical System Piston Pump

Name: AA10VSO45DFR1/31R-PPA12N00 A10VSO71DRG/31R-PPA12N00 L10VSO100DFLR/31R-PPA12N00 HA10VSO45DR/31R-PPA12N00 L10VSO45DFR1/31R-PPA12N00German Rexroth Mechanical System Piston Pump
Brand: Guang Zhou PMD Machinery Parts co ltd

Price Negotiable

Price: 1

MOQ: 1

Delivery Time: 2weeks

Brand: Rexroth

Product Description

AA10VSO45DFR1/31R-PPA12N00 A10VSO71DRG/31R-PPA12N00 L10VSO100DFLR/31R-PPA12N00 HA10VSO45DR/31R-PPA12N00 L10VSO45DFR1/31R-PPA12N00German Rexroth Mechanical System Piston Pump

hydraulic system	high pressure	electric	cast iron	construction machinery
hydraulic oil	variable	vertical	Rexroth	plunger pump	hydraulic
Edge standing	wooden box	nationwide	pipeline pump	Edge standing	plunger pump
Used in the mechanical industry

A10VSO 45 DFR/31R-PPA12N00

A10VSO 45 DFR/31L-PPA12N00

A10VSO 45 DFR1/31R-PPA12N00

A10VSO 45 DFR1/31L-PPA12N00

A10VSO 45 DFLR/31R-PPA12N00

A10VSO 45 DFLR/31L-PPA12N00

A10VO 45 DFR/31R-VSC12K01

A10VO 45 DFR/31L-VSC12K01

FAQ；

1. What is the A10VSO Series Pump?

The A10VSO is a variable displacement axial piston pump designed for hydraulic systems operating with mineral oil-based fluids. It features a swashplate design that allows adjustable flow rates (from 0 to maximum) to match system demand, making it ideal for applications requiring energy efficiency and flexible performance.

Key characteristics include:

High operating pressure capability
Compact design with low noise emissions
Variable displacement for on-demand flow control
Robust construction for long service life

2. What do the "A10VSO" designations represent?

The model code follows a standardized naming convention to define the pump’s key parameters:

Code Segment	Meaning
A	Design family: Axial piston pump
10	Size code: Indicates the nominal displacement (correlates to frame size)
V	Variable displacement: Allows flow rate adjustment
S	Swashplate design: Flow control via swashplate angle adjustment
O	Outlet connection type: Standard port configuration

4. What are the key technical specifications of A10VSO Pumps?

Standard specifications (varies by model) include:

Specification	Typical Range
Displacement	18–140 cm³/rev (cubic centimeters per revolution)
Maximum Operating Pressure	350 bar (continuous), 400 bar (peak)
Maximum Speed	1,800–3,600 rpm (depending on model)
Fluid Compatibility	Mineral oil (ISO VG 10–68), water-glycol (with modifications)
Operating Temperature	-20°C to +80°C (fluid temperature)
Efficiency	Up to 92% (overall efficiency at nominal load)
