Product Description
JSSCD-160NC/P CNC High Speed Circular Saw Machine (Horizontal-Push)
Achieving demanding standards in modern metal fabrication requires cutting solutions that combine exceptional speed with unwavering precision. This advanced CNC horizontal circular saw meets this critical need, delivering rapid cutting cycles, automated accuracy, and efficient energy usage for productive metal processing operations.
Core Capabilities & Intelligent Design
- Innovative horizontal insertion cutting system with AC Servo Motor and precision ball-screw drive
- Robust hydraulic clamping system (horizontal/vertical hold-down) for diverse material shapes
- High-strength construction ensures material stability at peak operating speeds
- Consistent cut quality and high repeatability for intensive continuous production
Sustained Precision & Dependable Operation
- Integrated backlash compensation mechanism maintains precision during prolonged use
- Dual lubrication system (self-lubricating and micro-lubrication) minimizes wear
- Efficient chip conveyor with magnetic particle brake enhances safety and maintenance
- Carbide-tipped parallel guides ensure orderly workpiece discharge
Boosting Throughput with Automation
Optional high-capacity automated material handling system enables continuous, unattended feeding for maximum output. This integration supports uninterrupted batch processing, maximizing machine utilization and production line efficiency.
Technical Specifications
| Model | Unit | JSSCD-160NC/P |
|---|---|---|
| Mainframe dimensions | mm | 2240*2320*2040 |
| Bar & round pipe | mm | 40-160 |
| Angle bar & square bar | mm | 40-130 |
| Saw blade size | mm | φ480*2.7*φ50 |
| Spindle motor power | KW | 18.5/15 |
| Spindle speed | rpm | 20-110 |
| Feed servo motor power | KW | 2.3 |
| Feeding servo motor power | KW | 2.7 |
| Material removal length at the front end | mm | 10-99 |
| Single feeding length (repeatable) | mm | 10-800 |
| Hydraulic drive motor power | KW | 3.75(4p) |
| Rated pressure of the hydraulic system | mpa | 5.5 |
| Hydraulic oil capacity | L | 110 |
Smart Control & Simplified Operation
The sophisticated CNC control system precisely governs cutting parameters for consistent quality. The intuitive operator interface (HMI) allows for straightforward setup and operation, with program management capabilities that reduce operator workload and minimize errors.
Frequently Asked Questions
Are you a manufacturer or a trading company?
We are a professional manufacturer of saw blade grinders with a 30,000 square meter factory and dedicated technical team.
Where is your factory located?
Our factory is located in Nantong City, Jiangsu Province, China, approximately 1.5 hours from Shanghai Hongqiao station.
What is your factory acceptance test method?
We perform test cuts with sample materials you provide and share detailed cutting data along with video documentation.
What is your method of transaction?
We typically use FOB (Free On Board) transactions, with 30% deposit and 70% balance before shipment.
Does the band saw blade have any international certifications?
Yes, we have obtained CE and ISO international certifications.
