Speedy Plastic Card Die Cutting Machine Semi Automaitic YLP-4 For 4*8 Layout
Price:
negotiable
MOQ:
1 set
Delivery Time:
20-25days
Brand:
YL
Product Description
Speedy Plastic Card Die Cutting Machine Semi Automatic YLP-4 For 4×8 Layout
Key Specifications
| Attribute | Value |
|---|---|
| Max speed | 12000-14000 cards per hour |
| Applicable PVC sheet layout | 4×8/4×10 |
| Machine's Dimension | 1700mm×800mm×1500mm |
| Net Weight | around 700kgs |
| Compressed air | 6KG/CM² |
| Hydraulic pressure | ≤30Kg/CM |
Product Overview
The Semi-Automatic Speedy Plastic Card Die Cutting Machine YLP-4 is designed for punching laminated plastic sheets (4×8/4×10 layout) into ISO CR80 cards with speed and precision.
Key Features
- High-quality PLC, touch screen and servo system for machine stability
- Precision guide screws ensure accurate card conveying and punching
- Reliable hydraulic system for low noise and stable pressure control
- Specially designed punching mold for perfect results and long service life
Technical Specifications
| Max speed | 12000-14000 cards per hour |
| Applicable PVC sheet layout | 4×8/4×10 |
| Dimension | 1700mm×800mm×1500mm |
| Weight | about 700kgs |
| Power supply | AC380V 50/60HZ |
| Power rating | 2.5kw |
| Compressed air | 6KG/CM² |
| Hydraulic pressure | ≤30Kg/CM |
Applications
The Speedy Plastic Card Puncher YLP-4 (also known as Card Punching Machine or Card Die Cutting Machine) is designed for semi-automatic punching of plastic card PVC sheets (4×8/4×10 layout around size in 210×297mm).
