High Speed Ultrasonic Card Packaging Machine 0.25mm - 0.8mm Thick 30000 pcs/hr
Price:
negotiable
MOQ:
1 set
Delivery Time:
30-35days
Brand:
YL
Product Description
Ultrasonic Cell Phone Charge Card Packaging Machine High Speed Automatic Checking
Product Specifications
| Control Method | PLC programming + Step System |
|---|---|
| Dimension | L4800×W980×H1860mm |
| Packaging Material | BOPP film or similar 0.025mm~0.035 mm thick |
| Card size | 0.25-0.8mm thick CR80 cards |
| Packaging Size | Folded film 120 mm wide (for standard card) or 60mm wide (for half size card), Film roll inner diameter 3 inches and external diameter less than 450 mm |
| Speed | Max 30000 pcs/hr |
Product Overview
The Automatic High-Speed Ultrasonic Card Packing Machine YUP-3000 delivers perfect single-card or multi-card packaging using continuous ultrasonic welding technology at high speeds. PLC-controlled with an intuitive interface, this machine offers fast operation, low noise, precise welding patterns, and reliable performance for bulk packaging of cell phone charge cards and SIM cards.
Key Features
- Special rubber wheel and air absorbing belt ensure flat, stable film conveyance
- Automatic detection for card overlapping/absence with error notification
- Optional second feeder for double cards or mini booklet insertion
- Continuous ultrasonic welding technology for clear, attractive sealing patterns
- Configurable for single or multiple card packaging
- Optional visual inspection system for serial number/barcode verification
- Optional chain card binding unit for packed chain cards
Technical Parameters
| Power Supply | AC 380V/50 HZ |
|---|---|
| Total Power | 5KW |
| Air Source | 6 kg/cm² (Dry) |
| Air Consumption | 50L/min |
| Weight | Approximately 1000Kg |
| Operator Requirement | 1 person |
Applications
Also known as Speedy Card Packaging Machine, High-speed Card Wrapping Machine, Card Wrapper or Card Packer YUP-3000, this system is ideal for high-volume packaging of various card types including phone cards and SIM cards.
