0.4mm - 1.0mm Smart Card Material Silk Laminated Steel Plate For RFID Card Production
Price:
Negotiable
MOQ:
50pcs
Delivery Time:
10-15days after receiving the prepayment
Brand:
YL
Product Description
Silk Lamination Steel Plate RFID Inlay Card Laminating Prelam Production Materials YSP-S
Product Attributes
| Attribute | Value |
|---|---|
| Surface | Fine silk/Rough silk |
| Plate size | A4,A3,A3+ or customized |
| Usage | Plastic RFID Card |
| Dimension tolerance | ±1mm for length and width |
| Feature | Two sides have the silk pattern in the same quality |
| Plate edge | Round curved corners |
Product Overview
These steel plates serve as essential consumables in plastic card lamination, ensuring perfect surface finish for RFID cards. Widely used by card manufacturers globally, our plates offer superior heat conduction, pressure resistance, and high-quality mirror finish for producing international standard cards.
Key Features
- Both surfaces protected by blue films (no residual glue after removal)
- Consistent gloss/matte quality on both sides
- Free from scratches, dents, stripes, shadows, and dust
- Smooth, deburred edges with rounded corners
- Non-stick surface prevents adhesion to laminated plastic sheets
Specifications
| Parameter | Details |
|---|---|
| Product name | Silk Lamination Steel Plate |
| Thickness | 0.4mm-1.0mm |
| Surface options | Mirror, glossy, matte, silk, patterned or custom |
| Material | 304BA stainless steel |
| MOQ | 50pcs (free samples available) |
| Application | Smart card laminating process |
Technical Parameters
| Plate size | A4, A3 or custom-made |
| Thickness tolerance | ±0.05mm |
| Flatness level | Maximum 1 mm.m |
| Surface roughness | Fine silk/Rough silk |
| Surface glossiness | Over 800 GU at 20° (both sides) |
| Surface hardness | HRC26±2 |
| Thermal transmission | 0.04cal/℃.cm.sec at 20℃ |
| Packaging | Plywood carton with cushion protection |
Product Variants
Available in five specialized surface types:
- Glossy steel plates
- Matte steel plates (ideal for planographic and inkjet coding)
- Silk matte steel plates
- Grained matte steel plates
- Custom pattern steel plates
Standard sizes: 100×120mm, 210×297mm (A4), 210×320mm, 325×480mm, 340×500mm or custom
Available thicknesses: 0.6mm, 0.8mm, 1.0mm
