High Glossy Mirror Finish Lamination Steel Plate For Smart Cards Production
Price:
negotiable
MOQ:
1 set
Delivery Time:
10-15days after receiving the prepayment
Brand:
YL
Product Description
High Glossy Mirror Finish Card Lamination Steel Plate For Smart Card Production
Product Specifications
| Attribute | Value |
|---|---|
| Plate size(L×W) | A4, A3 or custom-made size |
| Plate thickness | 0.4mm, 0.6mm, 0.8mm, 1.0mm (Thickness tolerance: ±0.05mm) |
| Dimension tolerance | ±1mm for length and width |
| Plate flatness level | Maximum 1 mm.m |
| Surface roughness | Glossy plate (Ra＜0.03μm) |
| Glossy plate surface glossiness | Over 800 GU at 20° (both sides) |
Product Description
0.4-1.0mm Thick High Glossy Mirror Finish Card Lamination Steel Plate YSP-G For Smart Card Production
High glossy lamination plate, ultra glossy lamination plate, lamination steel plate for card laminator, glossy/mirror laminating plate, card finish lamination plate, card production material
Product Introduction
These plates are essential consumables in plastic card lamination, ensuring perfect surface finish on laminated plastic cards. Widely used by card manufacturers globally, our plates deliver consistent quality results.
Key Features
- Both sides protected with blue film that leaves no residue when removed
- Consistent glossy/matte finish quality on both surfaces
- Free from scratches, dents, stripes, shadows, and dust
- Smooth, deburred edges with rounded corners for safety
- Non-stick surface prevents adhesion to laminated plastic sheets
Technical Parameters
| Surface hardness | HRC80±20 |
| Thermal transmission | 0.04cal/℃.cm.sec at 20℃ |
| Packaging | Solid plywood carton with soft cushion protection |
Applications
Also known as mirror finish plastic card laminating plate or high glossy card press steel plate, this product is essential for professional smart card production.
