1818 Series 2835 LED Neon Flex Light Strip 2700K / 3000K / 4000K / 6500K / RGB 24V
Price:
Contact us to get best price
MOQ:
100M
Delivery Time:
2-3weeks
Brand:
RELIGHT
Product Description
Features:
- 1. Large size, high luminous flux, long cascade, white light/color light optional
- 2. Copper backing reinforcement for enhanced tensile resistance, high mechanical reliability
- 3. High protection rating IP65/67/68 optional
- 4. Uniformlight emission, good appearance consistency
- 5. Anti-yellowing, high temperature resistance, corrosion resistance,weak acid and alkali resistance
- 6. Good flexibility, small size, light weight, easy installation
- 7. Food-grade environmentally friendly silicone material.
- 8. 3 years warranty
Technologies: ON/OFF, Dali, PWM, 0-10V, DMX2PWMDimmer, Radio Frequency control
Application:
This product is suitable for engineering projects, park lighting, buildingshotels, shopping malls, swimming pools, and other decorative lightingpurposes.
Product Description
| P/N | LED Quantity | CCT(K) | CRI | LED | Lumens (lm/m) | Vf. | Current (mA/m) | Power (W/m) | Cut Length(MM) | Max Run |
| (SM) | (v.) | |||||||||
| RL-FV2410140283510-XXX-FWD1818 | 2835 | 2700 | 80/90 | 140 | 500 | 24V | 417mA | 10 | 50mm | 5m |
| 3000 | 500 | |||||||||
| 4000 | 520 | |||||||||
| 6500 | 520 | |||||||||
| RL-FV2410140283510-8CW-FWD1818 | 2835 | 2700+6500 | 80/90 | 192 | 450 | 24V | 417mA | 10 | 62.5mm | 5m |
| RL-FV2410060505010-RGB-FWD1818 | 5050 | R:620-625nm | 80/90 | 60 | 140 | 24V | 417mA | 10 | 100mm | 5m |
| G:520-525nm | ||||||||||
| B:465-470nm | ||||||||||
| RL-FV2410060505010-RGBW-FWD1818 | 5050 | R:620-625nm | 80/90 | 60 | 340 | 24V | 500mA | 10 | 100mm | 5m |
| G:520-525nm | ||||||||||
| B:465-470nm | ||||||||||
| W:2700-6500 | ||||||||||
| RL-FV2410060505010-SPI-FWD1818 (1M10pixels) | 5050 | R:620-625nm | / | 60 | 190 | 24V | 542mA | 10 | 100mm | 5m |
| G:520-525nm | ||||||||||
| B:465-470nm | ||||||||||
| RL-FV2410060505010-DMX-FWD1818 (1M10pixels) | 5050 | R:620-625nm | / | 60 | 380 | 24V | 542mA | 10 | 100mm | 5m |
| G:520-525nm | ||||||||||
| B:465-470nm | ||||||||||
| W:2700-6500 |
Other Specifications
| Protection grade | IP67 |
| Working temperature(°C) | -25~+60 |
| Storage environment temperature (°C) | -25~+70 |
| Standard length | 5 |
| Maximum cascade length(m) | 5 |
| weight | / |
Remark
-
The test environment temperature is 25±2°C;
-
The above data are typical values, the actual parameters of the product may be different from the typical data; the data is subject to change without notice;
-
The above "/" means that this parameter is not required for the time being.
