1212 Top Bend Series High Efficiency LED Strip 2835 2700K - 4000K 24V RGBW LED Strip
Features:
Using silicone extrusion process, 12*12Mini size design
Uniform light emission, good appearance consistency
An yellowing, high temperature resistance, corrosion resistance, weak acid and alkali resistance,weak acid and alkali resistance
Good flexibility, small size, light weight, easy installation
Food-grade environmentally friendly silicone material
Waterproof grade IP67
5 years warranty
Product Description
| LED Quantity |
CCT k |
CRI | LED (SM) |
LUMENS (lm/m) |
VIN (v) |
Current (mA/M) |
Power (W/M) |
Cut Length (MM) |
Max Run (M) |
| 2835 | 2300 | 80/90 | 180 | 1400 | 24 | 416 | 10 | 50 | 5 |
| 2700 | 1400 | ||||||||
| 3000 | 1500 | ||||||||
| 4000 | 1500 | ||||||||
| 2835 8pixel/M |
2300 | 80/90 | 112 | 400 | 24 | 416 | 9.6 | 62.5 | 5 |
| 2700 | 400 | ||||||||
| 3000 | 400 | ||||||||
| 4000 | 400 | ||||||||
| 2835 12pixel/M |
R:620-630mm | 80/90 | 84 | R:28 | 24 | 416 | 9.6 | 83.3 | 5 |
| G:520-530mm | G:100 | ||||||||
| B:465-475mm | B:24 | ||||||||
| W:2700-6500K | W:90 |
Other Specifications
| Protection grade | IP67 |
| Working temperature(°C) | -25~+60 |
| Storage environment temperature (°C) | -25~+70 |
| Standard length | 5 |
| Maximum cascade length(m) | 5 |
| weight | / |
Remark
-
The test environment temperature is 25±2°C;
-
The above data are typical values, the actual parameters of the product may be different from the typical data; the data is subject to change without notice;
-
The above "/" means that this parameter is not required for the time being.
