300W AC100-277V Dimmable LED Driver DC24V Customizable Waterproof LED Driver with 5-Year Warranty
Price:
$1.09-32.90/pieces
MOQ:
2 pieces
Delivery Time:
20-25 days
Brand:
KSPOWER
Product Description
Customizable 300W LED Light Driver Waterproof LED Driver IP65 AC 260V DC 12V
12V 24V 36V 48V 120W Class P driver, 0/1-10V, 10V PWM, Resistance dimming 4 in 1 dimmable LED driver is constant voltage solution, and the perfect choice for under cabinet lighting and other residential and commercial lighting fixtures.
Applications
KS-300W is a versatile 300W 5-in-1 universal dimming driver that accepts 100-277VAC input voltage and provides 12V 24V 36V 48V constant voltage output. KS-300W delivers flicker free dimming to 0% on all dimming systems including 0-10V, 1-10V, Triac-Phase cut, PWM, Resistance, MLV, ELV and Incandescent. The high efficiency of the driver and sophisticated overload protection enables the electronics to run cooler and significantly improve reliability while extending product life.
The compact metal case is dry/damp location listed and IP65 rated, making it suitable for a wide range of indoor/outdoor architectural, commercial, industrial, and residential lighting applications. KS-300W is available with or without integrated junction boxes on both the input and output side that have two knockouts each.
Features
- Input Voltage: Universal 100VAC to 277VAC, 50/60Hz for Residential, Commercial, and Industrial Use
- Single Channel & Constant Voltage mode
- Output Voltage: 12Volt/24Volt/36Volt/48Volt
- Driver Type: Class 2 Class P
- Enclosure: LISTED Enclosure with Junction Box / LISTED Enclosure without Junction Box
- Dimming: PWM, 0/1-10V or MLV / ELV Resistance Dimmable Available
- Environmental: Dry and Damp
- Wiring Compartments with Knock-Outs for Clean and Easy Installation
- Current Limiting Overload Protection
- Flicker-Free
- Smooth Ripple Free Output Voltage
- IP65 Rated Enclosure for Indoor and Outdoor Use
- 5-Years Warranty
- UL/cUL CE FCC RoHS ENEC GS Listed, SELV, Type HL
Note: Any custom label/package/case is acceptable, provide OEM and ODM service
Technical Specifications
| Dimming Type | Series | Power | Model (xx=output voltage) | Output voltage | Output current | Input voltage | Size |
|---|---|---|---|---|---|---|---|
| 5 in 1 dimming | HPJ | 40W | KS-40AW-xxP | 12V24V/36V/48V | 3.3A | 1.67A | 1.11A | 0.83A | 100~277V 50/60Hz | 297*58*36mm |
| 60W | KS-60AW-xxP | 5A | 2.5A | 1.67A | 1.25A | 297*58*36mm | ||||
| 80W | KS-80AW-xxP | 6.67A | 3.33A | 2.22A | 1.67A | 297*58*36mm | ||||
| 96W | KS-96AW-24P | / | 4A | / | / | 322*58*36mm | ||||
| 100W | KS-100AW-xxP | 8.33A | 4.16A | 2.78A | 2.08A | 322*58*36mm | ||||
| 120W | KS-120AW-xxP | 10A | 5A | 3.33A | 2.5A | 322*58*36mm | ||||
| 150W | KS-150AW-xxP | 12.5A | 6.25A | 4.16A | 3.13A | 343*68*41mm | ||||
| 180W | KS-180AW-12P | 15A | / | / | / | 343*68*41mm | ||||
| 200W | KS-200AW-xxP | 16.66A | 8.33A | 5.55A | 4.16A | 343*68*41mm | ||||
| 240W | KS-240AW-xxP | 20A | 10A | 6.66A | 5A | 367*68*41mm | ||||
| 300W | KS-300AW-24P | / | 12.5A | / | / | 367*68*41mm | ||||
| 320W | KS-320AW-xxP | / | 13.33A | 8.88A | 6.66A | 367*68*41mm |
