19inch 300cd/m2 LTM190M2-L31 WXGA TFT-LCD Display Screen Panel for Desktop Monitor ATM Commercial System PC Computer
Price:
$99/pieces 1-499 pieces
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
SAMSUNG
Product Description
Products Description
Panel Model | LTM190M2-L31 | Panel Brand | SAMSUNG |
Size (inch ) | 19inch | Panel Type | a-Si TFT-LCD, LCM |
Resolution | 1440(RGB)×900, WXGA+ 89PP | Pixel Format | RGB Vertical Stripe |
Module Outsize(mm) | 428(W)×278(H) ×18.5(D) mm | Display Mode | TN, Normally White, Transmissive |
LCD Active area(mm) | 408.24(W)×255.15(H) mm | Response Time | 1.3/3.7 (Typ.)(Tr/Td) |
Display Colors | 16.7M 100% sRGB | Light Source | 4 pcs CCFL , 50K hours , Without Driver |
Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) | Touch Screen | Without |
Brightness | 300 cd/m² (Typ.) | Power Supply | 5.0V (Typ.) |
Contrast Ratio | 1000:1 (Typ.) (TM) | Used for | Industrial, Desktop Monitor |
Frame Ratio | 60Hz | Enviroment | Storage Temp.: -25 ~ 60 °C |
Operating Temp.: -0 ~ 50°C | |||
LCM Interface Type | LVDS (2 ch, 8-bit) , 30 pins Connector | FPC connector | UJU, IS100-L30R-C23, Pitch 1.0mm |
Details Images
Company Profile
FAQ
Q1. What is your lead time? A: Stock: 5-15 days in general. No stock: 15-30 days after samples confirmed. Or please contact us by email for specific lead time base on your order quantities. Q2. How does your factory do regarding quality control? A: Quality is priority. We always attach great importance to quality control from the very beginning to the end: 1) All raw material we used are non-toxic, environmental-friendly; 2) Skillful workers pay great attention to each details in handling the producing and packing processes; 3) We have a professional QA/QC team to ensure the quality. Q3. Do you accept OEM or ODM order? A: Yes, we accept both OEM and ODM for customers. Q4. What are your terms of delivery? A: We can accept EXW, FOB, CIF, etc. You can choose one which is the most convenient for you. Q5. What is the payment way? A: TT, Pay Later, West Union,Online Bank Payment. Should you have other questions, please let us know. We’ll add answers here for your further references. Thank you.
