TFT-LCD 12.1 Inch WXGA 1280x800 400nits LVDS Interface Industrial Lamp Replaceable Display Screen for Innolux G121I1-L01
Price:
$153/pieces 1-99 pieces
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
Innolux
Product Description
Products Description
Panel Model | G121I1-L01 | Panel Brand | Innolux |
Size (inch ) | 12.1inch | Panel Type | a-Si TFT-LCD, LCM |
Resolution | 1280(RGB)×800, WXGA 124PPI | Pixel Format | RGB Vertical Stripe |
Module Outsize(mm) | 278 × 184 × 10.5 (H×V×D) | Display Mode | MVA, Normally Black, Transmissive |
LCD Active area(mm) | 261.12(W)×163.2(H) mm | Response Time | 15/10 (Typ.)(Tr/Tf) ms |
Display Colors | 262K/16.2M 45% NTSC | Light Source | 9S3P WLED , 50K hours , With LED Driver |
Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) | Touch Screen | Without |
Brightness | 400 cd/m² (Typ.) | Power Supply | 3.3V (Typ.) |
Contrast Ratio | 1000:1 (Typ.) (TM) | Used for | Industrial, Outdoor High Brightness |
Frame Ratio | 60Hz | Enviroment | Storage Temp.: -20 ~ 80 °C |
Operating Temp.: -10 ~ 70°C | |||
LCM Interface Type | LVDS (1 ch, 6/8-bit) , 30 pins Connector | FPC connector | Starconn, 093G30-B0001A-G4, Pitch 1.0mm |
