Industrial PMP VOIP Phone Video Door Phone Digital Photo Frame Innolux AT056TN52 V.3 5.6 Inch VGA 640x480 Display Panel
Price:
$33/pieces 1-99 pieces
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
Innolux
Product Description
Products Description
Panel Model | AT056TN52 V.3 | Panel Brand | Innolux |
Size (inch ) | 5.6inch | Panel Type | a-Si TFT-LCD, LCM |
Resolution | 640(RGB)×480, VGA 143PPI | Pixel Format | RGB Vertical Stripe |
Module Outsize(mm) | 126.5(W)×100(H) ×6(D) mm | Display Mode | TN, Normally White, Transmissive |
LCD Active area(mm) | 112.896(W)×84.672(H) mm | Response Time | 10/15 (Typ.)(Tr/Td) |
Display Colors | 16.7M | Light Source | 3S5P WLED , 20K hours , Without Driver |
Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) | Touch Screen | Without |
Brightness | 200 cd/m² (Typ.) | Power Supply | 3.3/5.0/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
Contrast Ratio | 500:1 (Typ.) (TM) | Used for | Industrial |
Frame Ratio | 60Hz | Enviroment | Storage Temp.: -30 ~ 80 °C |
Operating Temp.: -20 ~ 70 °C | |||
LCM Interface Type | Parallel RGB (1 ch, 8-bit) , 50 pins FPC | FPC connector | Pitch 0.5mm |
Details Images
