Oil Sludge Treatment System Centrifugal Pumps Compact Centrifugal Slurry Pump
SB 2×3 Centrifugal Mud Pump for Oil Sludge Treatment System Compact and Reasonable Structure
- Maximize fluid transfer efficiency with SB series’ optimized impeller and volute design. The SB2×3J-8 model achieves 54% efficiency at 40m³/h flow and 16m head, reducing energy consumption with 5.5kW motor power. Wide-flow-path impellers prevent clogging from solids-laden mud, minimizing downtime in shale shaker or desilter applications.
- •
Solids Control: SB2×3J series handles 25–55m³/h for desander/desilter feed in mud recycling systems.
- •
Cuttings Evacuation: Non-clogging impellers transport ≤15mm solids without jamming.
- •
Rig Support: Compact size (≤1.35m length) enables deployment in mobile land rigs or offshore platforms.
Technical specs: Max 11kW power, 1760 RPM speed, 320kg weight.
Features
Patented Seal Technology - Service life is 6 times longer than an ordinary mechanical seal. (Patent No. ZL200720079857.2)
High Efficiency - The impeller and pump shell port are designed with optimal streamlining.
Long Service Life - The overflow parts are made of highly wear-resistant cast iron.
Non-clogging - The impeller is designed with a wide flow path.
Patented Appearance - Compact and reasonable structure (Patent No. ZL200730094452.1).
| Model | Flow (m³/h) | Head (m) | Rotational Speed(rpm) | Efficiency (%) | Power (kW) | Weight (kg) | L*W*H (mm) | ||
| / | / | / | 50Hz | 60Hz | / | Shaft Power | Motor Power | / | / |
| SB2 × 3J - 10 | 55 | 22 | 1460 | 1760 | 60 | 5.5 | 11 | 320 | 1352×446×682 |
| SB2 × 3J - 9 | 50 | 18 | 1440 | 1750 | 56 | 4.4 | 7.5 | 260 | 1232×446×650 |
| SB2 × 3J - 8 | 40 | 16 | 1440 | 1750 | 54 | 3.2 | 5.5 | 245 | 1192×446×650 |
| SB2 × 3J-7½ | 25 | 11 | 1440 | 1750 | 50 | 1.5 | 4 | 223 | 1161×446×600 |
