ZK Three Phase Bowl Diameter Length 520mm Deacnter Centrifuge: 70 m³/h Durable Decanter Centrifuge: Duplex Steel Construction, 60~70 m³/h Throughput

Process 20–40 m³/h of drilling mud at 2–4% solids, achieving effluent solids <0.05%. The 4.1 length-diameter ratio enhances separation clarity under variable inflow. Sludge cakes reach 65–81% dryness, reducing disposal costs

The 8000Nm differential torque system compacts sticky petroleum sludge into 35% drier cakes versus competitors. Adjustable RPM fine-tunes dewatering without clogging, ensuring stable performance during drilling fluid surges.

Features

• Remove up to 99.5% of total suspended solids (TSS) in optimized wastewater treatment processes—ensuring high-effluent clarity and regulatory compliance.
• Engineered for continuous 24/7 operation, with over 99% system uptime to support critical wastewater treatment processes.
• Smart automation adjusts in real time to shifting flow rates, cutting manual monitoring and keeping your plant stable and efficient—day and night.
• Modular design enables scalable system expansion—whether adding throughput capacity or integrating with existing wastewater treatment lines.
• Equipped with energy-efficient VFD drive systems, our centrifuges reduce power consumption by up to 25% compared to conventional models—lowering long-term operating costs.
• Key components are built from duplex stainless steel (SS316L/SS2205), providing exceptional resistance to corrosion, abrasion, and chemical attack—ideal for harsh wastewater environments.


  		Model
  			LW520×2150E
  Capacity	Solid Content	0.8~1%	60~70
  		1~2%	40~60
  		2~4%	20~40
  		4~5%	15~20
  Bowl Diameter(mm)			520
  Length-Diameter Ratio(mm)			4.1
  Speed(rpm)			3000
  Designed Separation Factor			2620
  Differential Speed(rpm)			1~34
  Differential Maximum Torque(Nm)			8000
  Main Motor power(KW)			55~75
  Back motor power(kW)			11~15
  Total Length(mm)			5100
  Width(mm)			1250
  Height(mm)			1600
  Weight(Kg)			5200
