Copy function
Copy resolution: Max 600 × 600dpi (input)
three hundred and sixty × 360dpi，720 × 720dpi (print)
three hundred × 300dpi，300 × 600dpi (input, flat panel)
Continuous copy: Page 1-20
Zoom range: actual
Copy other properties: Maximum copy size: Legal
Color: 256 gray levels / 16.7 million colors
Scanning function
Scan controller： Standard configuration
Scan type ： Flat panel (color image scanner)
Scanning element: CIS
Optical resolution： 600dpi
Maximum resolution： Maximum physical resolution: 1200 × 2400dpi, maximum resolution: 9600dpi
Scan size ： Maximum 216 × 297mm（8.5 × 11.7 inches)
Color depth： Color: 48 bit input, 24 bit output
Grayscale:：16 bit input, 8-bit output
Black and white： 16 bit input, 1-bit output
Scan other performance Compatibility: Twain / WIA / ICA
Support scanning to computer, computer (WSD)
Media specification
Medium size Maximum paper size supported: Legal
Borderless: 4 × 6 inches, 16:9100 × 148mm，3.5 × 5 inches
Print margin: up / down / left / right: borderless size: 0mm (with margin, minimum 3mm)
Medium weight Plain paper: 64-90g / ㎡, high quality glossy photo paper: 102-300g / ㎡
Supply carton capacity Number of feeding cartons: 1
Rear feed: 100 pages of A4 / LTR plain paper (80g / ㎡)
Output capacity 30 pages A4 plain paper, 20 pages high quality glossy photo paper (face up)
Other parameters
system platform Windows XP Professional SP2 (64 bit) / XP SP3 (32 bit) / Vista / 7 / 8 / 8.1/10 (32 / 64 bit) / Server 2003 SP2 / 2003 R2 / 2008 / 2008 R2 / 2012 / 2012 R2 / 2016
Mac OS X 10.6.8，10.7.x，10.8.x，10.9.x，10.10.x，10.11.x，10.12.x，10.13.x
Interface type High speed USB, IEEE 802.11b/g/n
Product size three hundred and seventy-five × three hundred and forty-seven × 179mm (when the output tray is closed), 375 × five hundred and seventy-eight × 253mm (when the output tray is open)
Product weight 3.9kg (excluding cartridge / power cord)
Environmental parameters Working temperature: 10-35 ℃, working humidity: 20-80% RH
Storage temperature: - 20-40 ℃, storage humidity: 5-85% RH
Other features Minimum ink drop: 3 μ L
Network protocol: TCP / IPv4, TCP / IPv6
Network printing protocol: LPD, port9100, WSD
Network management protocols: SNMP, HTTP, DHCP, APIPA, Ping, DDNS, mDNS, SLP, WSD, LLTD
Wi Fi direct: Yes, up to 8 devices can be connected at the same time
WLAN Security: WEP (64bit / 128bit), wpa-psk (TKIP), wpa2-psk (AES)
Intelligent: innovative intelligent ink filling system to effectively prevent wrong ink filling and leakage
Compact: built in integrated ink bin design, smaller volume and space saving
Environmental protection: no taste, zero ozone emission, PM2.5 release
Wireless: Wi Fi + wireless direct connection, wireless printing and wireless scanning can be realized without routing
Convenience: support mobile phone printing, remote printing and receiving e-mail printing
