High Precision X6036 Universial Lift Table Milling Machine Manual Mill 220V 380V Optional

Price Negotiable

Price: 8000USD

MOQ: 1 set

Delivery Time: 15 days after getting the deposit.

Brand: Zaozhuang NO.1

Product Description

High Precision X6036 Universial Lift Table Milling Machine Manual Mill 220V 380V Optional

The X6036 is a high-performance universal milling machine, famous for its powerful cutting capacity and wide application range. Its horizontal spindle structure delivers outstanding rigidity, making it ideal for heavy-duty and high-efficiency milling of planes, grooves, gears, and various complex profiles with cylindrical cutters, slab cutters, and formed cutters.

Optional Configuration:

1.Vertical milling head

2.Three-axis digital display

3.Electronic oil pump

4.Universal dividing head

5.Custom tool holder

Product specification:

PARAMETER ITEM	UNIT	X6028	X6032	X6036
Working desk size	mm	1200/1500x280	1500x320	1500x360
Number of T-slots		3	3	3
Workbench trip	mm	680/280/350	1000x320x400	1000/360/400
Spindle hole taper		7:24/ISO40	7:24/ISO40	7:24/ISO50
Spindle speed range	rpm	40-1300(12 steps)	40-1300(12 steps)	60-1800(12 steps)
Worktable feed speed	mm/min	15-370 (8 steps)	15-370 (8 steps)	15-370 (8 steps)
Workbench down stroke	mm	500	500	500
Worktable vertical lifting speed	mm/min	560	560	560
Spindle center to vertical rail surface distance	mm	300	320	320
Vertical shaft end to table distance	mm	50-550	50-550	50-550
Motor Power	kw	3	3	4
Dimensions	mm	1460x1500x1900	1760x1500x1900	2220x1790x1980
Machine weight	kg	1500	2100	2400/2500
