SH8017 Petroleum Steam Pressure Tester Reid Method Manual Params & Packing List ASTM D323

1. Purpose and Scope of Application

II. Main Technical Specifications and Parameters

1. Operating power supply: AC220V±10%, 50Hz
2. Water bath heating power: 1600W
3. Water bath operating temperature range: Room temperature ~90℃
4. Water bath temperature control accuracy: ±0.1℃
5. Pressure gauge accuracy: ±0.4%
6. Ambient temperature: -10℃~35℃
7. Relative humidity: ≤85%
8. Total machine power consumption: ≤1700W

9. Description	Parameters
   Input power	AC 220V ± 5% 50Hz
   The use of water bath temperature range	room temperature ~100℃;
   Temperature control accuracy	± 0.1 ºC
   Heating power	1.6KW
   Pressure gauge	Round Hand gauge 0 ~ 200KPa
   pressure gauge accuracy	+ 0.4%;
   Ambient temperature	-10℃~35℃.
   Relative humidity	<85% RH
   Power consumption of the whole machine: no more than 1700W
   Package size: 48 * 45 * 75cm weight 50kg

10. Packing list



    S/N	Name	Unit	Quantity	Remarks
    1	Vapor pressure meter	set	1
    2	Steam bomb	set	2
    3	Pressure gauge	piece	2
    4	Mercury thermometer	piece	1
    5	Instruction	copy	1
    6	Packing list	copy	1
    7	Certificate warranty card	copy	1

12. Company Introduction

13. Shandong Shengtai Instruments Co., Ltd. is specialized in the research and production of experimental testing instruments and industrial testing instruments. It is a professional instrument company integrating instrument research and development, manufacturing, sales and service. Its products are widely used in food, flour, grain and oil, Feed, electricity, petrochemical, industrial oil, aerospace, coal quality and other industries.

    For more than 10 years, Shengtai has always been adhering to the "first-class service, customer first" as the purpose, "reasonable price, honesty and trustworthiness" as the business policy. Adhere to technical innovation, with rich knowledge of the technical team and experienced, thoughtful after-sales service team.

    Shengtai instrument as one of the most large-scale and competitive enterprises in the industry, with the strength of technology research and development, professional technical knowledge and innovative design concept, in the model improvement, Significant technical breakthrough has been achieved in the development of function expansion and intelligent control system.
