APC Schneider UPS GVSUPS20KHS Galaxy VS UPS 20kW 400V for External Batteries APC Galaxy-Ups 400 V 20kVA Price
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
APC
Product Description
Products Description
Specification
Lead time | Usually Ships within 2 Weeks | |
Main Input Voltage | 400 V 3 phases | |
Other Input Voltage | 380 V | |
415 V | ||
Main Output Voltage | 400 V 3 phases | |
Other Output Voltage | 380 V | |
415 V | ||
Rated power in W | 20 kW | |
rated power in VA | 20 kVA | |
Output connector type | Hard wire 5-wire (3P + N + E) 1 | |
Battery type | External battery system | |
Li-Ion (Lithium-Ion) | ||
Max bypass input current | 32 A | |
Redundant | No | |
Product or component type | Uninterruptible power supply (UPS) | |
Physical | ||
Colour | White | |
Height | 148.5 cm | |
Width | 52.1 cm | |
Depth | 84.7 cm | |
Net weight | 206 kg | |
USB compatible | No | |
Input | ||
Network frequency | 40...70 Hz | |
Number of input connectors | 1 hard wire 4-wire (3P + E) | |
1 hard wire 5-wire (3P + N + E) | ||
Input voltage limits | 340...460 V 400 V | |
Maximum input current | 37 A | |
Max short time withstand current | 65 kA | |
Input harmonic distortion | Less than 3 % for full load | |
Load power factor | From 0.7 leading to 0.7 lagging without any derating | |
Input Power Factor at Full Load | 0.99 | |
Crest factor | 2.5 | |
Wave type | Sine wave | |
Output voltage tolerance | +/-1% after 50ms | |
Output harmonic distortion | < 1% linear load and < 3% non-linear load | |
Output overload operation | 10 minutes at 125% and 60 seconds at 150% | |
Bypass type | Built-in static bypass | |
Maximum configurable power in VA | 20 kVA | |
Conformance | ||
Standards | CSA C22.2 No 107.3 | |
EN/IEC 62040-1 | ||
EN/IEC 62040-2 | ||
EN/IEC 62040-3 | ||
FCC part 15 class A | ||
IEC 60721-4-2 level 2M2 | ||
UL 1778 5th edition | ||
Environmental | ||
Ambient air temperature for operation | 0…40 °C | |
Relative humidity | 0…95 % non-condensing | |
Operating altitude | 0...3281 ft | |
Ambient air temperature for storage | -25…55 °C | |
Storage Relative Humidity | 10…80 % non-condensing | |
Storage altitude | 0…15240 m | |
Number of Units in Package 1 | 1 | |
Package 1 Height | 168 cm | |
Package 1 Width | 99 cm | |
Package 1 Length | 64 cm | |
Package 1 Weight | 235 kg | |
