Mini2 256 Thermal Imaging Camera Thermal Camera Hunting with CMOS Sensor Element for Security and Fire Inspection
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
MINI2 256
4mm Lens THERMAL CAMERA
The MINI2 256 series uncooled infrared module features high performance, small size, light weight, low power consumption, and low cost, meeting the application requirements of SWaP (Size, Weight, and Power/Price).
The entire series is equipped with a smooth and seamless algorithm, and is equipped with a new generation of infrared dedicated image algorithm, resulting in delicate and clear image quality.
The infrared thermal camera provides multiple digital interfaces that can be flexibly connected to various intelligent processing platforms.
Overview | MINI2 256 Thermal Camera |
Detector Type | Vanadium Oxide Uncooled Infrared Focal Plane Detector |
Resolution | 256×192 |
Effective Frame Rate | 25/50Hz |
Pixel Pitch | 12μm |
Spectral Band | 8～14μm |
NETD | ≤40mK@25℃,F#1.0,25Hz |
Thermal Time Constant | ＜12ms |
Image Adjustment | |
Non-uniformity Correction | Shutter correction/shutter-less algorithm correction |
Brightness/Contrast Adjustment | 0~100, optional |
Polarity/Palette | White-hot/Black-hot/Various palettes supported |
Digital zoom | 1.0~8.0×continuous zoom (step size: 0.1) |
Image Mirroring | Vertical/Horizontal/Diagonal |
Electricity Parameters | |
Analog Video | PAL/NTSC |
Digital Video | DVP/BT656/ USB2.0/MIPI |
Communication Interface | UART/I2C/USB2.0 |
Power Supply Input | 5V |
Typical power consumption of USB output @25℃ | ＜0.35W |
Physical Characteristics | |
Weight (without lens) | <7g |
Dimensions (without lens) | 21×21×10.3 mm |
Environment Adaptability | |
Operating Temperature | -40℃~+80℃ |
Storage Temperature | -50℃~+85℃ |
Humidity | 5%–95%, non-condensing |
Vibration | 6.06g, random vibration, all axes |
Impact | 80g, 4ms, final peak sawtooth wave, three axes and six directions |
Lens Selection
Lens size | FOV | Detection range | F Number |
9.1mm | 19.3°×14.5° | 1.1km | 1.0 |
15mm | 11.7°×8.8° | 1.7km | 1.0 |
25mm | 17.5°×14.0° | 2.8km | 1.0 |
