National Instruments PXI-2564 16-Channel SPST PXI Relay Module with 5A Switching Current and 10 MHz Bandwidth
Price:
$1,000/sets >=1 sets
MOQ:
one
Delivery Time:
Delivery time for minimum order quantity ≤ 30 days
Brand:
National Instruments
Product Description
OEM Supported National Instruments PXI-2564 PXI Relay Module for Customized
The National Instruments PXI-2564 (Part Number: 778572-64) is a 5A, 16-channel SPST PXI relay module featuring independent SPST relays. All installed relays are non-latching type, known for their low thermal offset and extremely low on-resistance. This module can be easily programmed via software, making it ideal for applications requiring medium to high power signal and load switching, such as automotive or automated test applications.
Key Features
- 16 independent SPST (Form A) relays with gold-plated contacts
- 5A maximum switching current per channel
- 10.4ms maximum operate time
- Mechanical relay life: 20 million cycles
- Electrical relay life: 100,000 cycles
- 10 MHz switching bandwidth
- 45 scans per second operation
- PXI trigger support with programmable pulse width (1µs to 62µs)
- Compatible with NI-SWITCH driver software and LabVIEW programming
Technical Specifications
| Specification | Value |
|---|---|
| Module Type | 3U, Single-slot PXI |
| Connector | 37-pin D-SUB male I/O |
| Maximum Switching Power | 750 VA per channel |
| Power Consumption | 5W at 5V |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 70°C |
| Dimensions | 8.5 x 0.8 x 5.1 inches |
| Weight | 9.5 oz |
Key Specifications
Scan Rate: 45 cycles/second
Bus Connector: PXI Hybrid
Maximum DC Switching Current: 5 A
Maximum DC Switching Voltage: 150 V
Relay Configuration: SPST (Normally Open)
Switching Bandwidth: 10 MHz
Number of Relays: 16
