National Instruments PXIe-4144 PXI Source Measure Unit with 4 SMU Channels 6 V Voltage Range and 500 mA Current Range
Price:
$10,000/stones >=1 stones
MOQ:
one
Delivery Time:
Delivery time for minimum order quantity ≤ 30 days
Brand:
National Instruments
Product Description
OEM Supported National Instruments PXIe-4144 PXI Source Measure Unit for Measurements
Product Overview
The National Instruments PXIe-4144 PXI Source Measure Unit (Part Number: 782432-01) is a comprehensive solution for wireless test systems (RFIC), integrating key instruments required for testing RFIC devices including transceivers, IF receivers, RF front-ends, modulators/demodulators, and other RF IC components.
Key Features
- Integrated 6.6 GHz Vector Signal Analyzer (VSA) and 6.6 GHz Vector Signal Generator (VSG)
- Source Measure Unit (SMU) for basic DC parameter estimation (open/short, leakage tests)
- High-speed digital I/O for capturing or generating digital baseband or control communication patterns
- Supports common communication protocols (SPI, I2C, JTAG)
- Customizable modulation schemes (AM, FM, PM, ASK, FSK, MSK, GMSK, PSK, QPSK, PAM, QAM)
- NI LabVIEW programming support for rapid system modification
- Single-frequency and multi-frequency measurement techniques
Technical Specifications
| Current Sensitivity | 150 pA |
|---|---|
| SMU Channels | 4 |
| Voltage Range | -6 V to 6 V |
| Maximum DC Power Sink | 3 W |
| Maximum DC Power Source | 3 W |
| DC Current Range | -500 mA to 500 mA |
| Bus Connector | PXI Express |
Applications
The PXIe-4144 is ideal for characterizing RFIC devices, measuring parameters such as Error Vector Magnitude (EVM), frame leakage, repetition balance, and more. Its flexible architecture allows for quick adaptation to specific testing requirements in wireless communication systems including ZigBee, WLAN, and WiMAX.
