Portable 110V/220V CNC Plasma Cutting Machine Fast Ship Easy Installation for Metal Decorate Board Industrial Civil-Economical
Price:
$448-588 / set
MOQ:
1 set
Delivery Time:
Negotiable
Brand:
Toploong
Product Description
NEW 2023 Toploong cnc plasma system built in THC!
Recommend TOPLOONG CNC Plasma:
1000*1500mm 3'x5' $521
1300*2500mm 4'x8' $588
Includes:
* Free Nesting software.
* System TPL-2100K 5inch color screen,THC system.
* Optional: add flame cut torch set $85.
* USA KOL Comment:“Realy easy to use, Really easy to set up! Really realy cheap & Deliver is fast! ” Video : https://youtu.be/SZ5cYDyZ5U4
Product Description
Specification
Main configuration | ||||||||
1 | Model | Flame cutting / Plasma cutting / both F & P | ||||||
2 | Effective cutting range(mm) | 2400*3000/ 1600*6000/2400*3000/1800*3000 etc. | ||||||
3 | Machine Input Voltage | 110V/220V, 50HZ/60HZ | ||||||
Plasma power input voltage | 3 PHASE 380V / 220v / 110V | |||||||
4 | motor | 3 | sets | Qingsheng or Start | ||||
5 | driver | 2 | sets | Qingsheng or Start | ||||
CNC system | 1 | sets | Shanghai Jiaoda fangling | |||||
6 | Plasma interface | 1 | sets | Top CNC Technology Co., Ltd. | ||||
7 | The electromagnetic valve | 1 | sets | Ningbo | ||||
8 | Secondary development software | 1 | sets | Wuhan Zhige Professional Edition | ||||
9 | package | 1 | sets | Self-locking wooden box | ||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
FAQ
fter the machine is installed, two steps are necessary.
1: Positioning test, adjust the positioning knob until the cutting gun touches the steel plate and is lifted to about 3mm.
2: Arc starting test: Press the test button, the plasma arc starts, and observe the actual arc pressure with a steel plate underneath. Adjust the setting to the actual value, and then you can use it normally.
CNC Guide video:
https://www.youtube.com/playlist?list=PL736LR4epEWUA1vXF-LAZRnJDQBDyhcyB
Buy Machine give free Nesting software, it intsal to your PC, it edit DXF DWG files, and arrange your own made drawings nicely on metal plate, then export file to G code.txt, then Use USB load the G code into CNC plasma, it read the file in USB and automatic cut your drawings. Guide Video:
https://www.youtube.com/playlist?list=PL736LR4epEWVl-HrsmmY4S9oosLP-YMRy
TPL NEST Software Download:
https://we.tl/t-nYWCUwpB0f
http://zc.sinocam.com:8091/HiNest/HiNest-SETUP-x64.zip
MINI By Air:P-1015 1000*1500mm
1. Head 380*310*400mm 11kg
2. Rails 1820*230*120mm 17kg
Total 2pkgs 0.11m³ 28kg
MINI +PLASMA :P-1015 1000*1500mm
1. Head 380*310*400mm 11kg
2. Rails 1820*230*120mm 17kg
3. PLASMA 510*265*500mm 40kg
Total 3pkgs 0.2m³ 68kg
MINI By Air: P-1325 rail cut by 2pcs
1. Head 380*310*400mm 11kg
2. Rails 1830*220*130mm 29kg
Total 2pkgs 0.11m³ 40kg
MINI By Air: P-1325 rail cut by 2pcs
1. Head 380*310*400mm 11kg
2. Rails 1830*220*130mm 29kg
3, PLASMA 510*265*500mm 40kg
Total 3pkgs 0.2m³ 80kg
MINI By sea: P-1325
1. Head 380*310*400mm 11kg
2. Rails 3000*230*120mm 30kg
3. PLASMA 510*265*500mm 40kg
Total 3pkgs 0.25m³ 81kg
