8t9079 3K9770 Plow Segment Bolt Excavator Track Undercarriage Parts
High Quality 8t9079 Track Bolts and Nuts, 3K9770 Plow Segment Bolt
NF Bulldozer Segment Bolt Nut Combo - 3X Lifespan Guarantee! Fix CAT Undercarriage Now!
2. Nut strength class
Nuts are also categorized into three strength classes: 8, 10 and 12. Different grades of nuts are made of different materials to suit different working environments and load requirements.
3. Material and mechanical properties of nuts
– Grade 10 nuts use 35# high carbon steel, its hardness is HRC28-32, tensile strength ≥ 900 MPa.
– Grade 12 nuts use 40Cr alloy steel, hardness increased to HRC33-38, tensile strength ≥ 1000MPa.
Excavator and bulldozer bolts and nuts are small, but its impact on mechanical properties and safety should not be ignored. I hope the analysis in this article can help you better understand and use these key components to ensure the safe and efficient operation of construction machinery.
| Part Number | Part Name | Fit Model | Size |
| 2B5484+7K1706 | TRACK BOLT & NUT | D2,933C | 7/16''- 20*1 9/16'' UNF |
| 2B5483 | NUT | 7/16''- 20 UNF | |
| TB9/16*1 3/4 | TRACK BOLT & NUT | 9/16''-18*1 3/4'' UNF | |
| 4K7038+7K2017 | TRACK BOLT & NUT | D3,D4,D4D,931,933,941,215 | 9/16''-18*1 5/8'' UNF |
| 7H3596+7K2017 | TRACK BOLT & NUT | 931933941 | 9/16''-18*1 15/16'' UNF |
| 2F1009 | TRACK BOLT | 9/16''-18*2'' UNF | |
| 5A3187+7K2017 | TRACK BOLT & NUT | 9/16''-18*3'' UNF | |
| TB9/16*3 1/8 | TRACK BOLT & NUT | 9/16''-18*3 1/8'' UNF | |
| 7H3606 | NUT | 9/16''-18UNF | |
| TB5/8*1 15/16 | TRACK BOLT & NUT | R130LC | 5/8''-18*1 15/16'' UNF |
| 7H3597+1M1408 | TRACK BOLT & NUT | D4,D5,D5H,D6,D7,953,955,97 | 5/8''-18*2 3/32'' UNF |
| TB5/8*2 3/32 | TRACK BOLT & NUT | R210 | 5/8''-18*2 3/32'' UNF |
| 9G3110+1M1408 | TRACK BOLT & NUT | 225,941,951C,951B | 5/8''-18*2 5/32'' UNF |
| SH8756 | TRACK BOLT | 225,941,951B | 5/8''-18*2 1/4'' UNF |
| TB5/8*2 1/2 | TRACK BOLT & NUT | 5/8''-18*2 1/2'' UNF | |
| TB5/8*2 3/4 | TRACK BOLT & NUT | 5/8''-18*2 3/4'' UNF | |
| TB5/8*3 | TRACK BOLT & NUT | 5/8''-18*3'' UNF | |
| 5A4104+1M1408 | TRACK BOLT & NUT | 5/8''-18*3 3/8'' UNF | |
| 3T3884+1M1408 | TRACK BOLT & NUT | 5/8''-16*3 1/2'' UNF | |
| TB5/8*3 3/4 | TRACK BOLT & NUT | 5/8''-18*3 3/4'' UNF | |
| TB5/8*4 | TRACK BOLT & NUT | 5/8''-18*4'' UNF | |
| 7H3607 | NUT | 5/8''-18 UNF | |
| 1S1859+1S1860 | TRACK BOLT & NUT | D6,D7,D7H,D8,D6H | 3/4''-16*2 5/32'' UNF |
| 144-32-11211 | TRACK BOLT | D60A,E,P,PL,S-6 | 3/4''-16*2 13/64'' UNF |
| 207-32-11310 | TRACK BOLT | D60A,E,P,PL,S-7 | 3/4''-16*2 13/64'' UNF |
| 150-32-21321 | TRACK BOLT | D65A,E,P,S-6 | 3/4''-16*2 3/8'' UNF |
| 154-32-21320 | TRACK BOLT | 65A,E,P,PL,S-7 | 3/4''-16*2 3/8'' UNF |
| 7H3598+1S1860 | TRACK BOLT & NUT | 2.35572E+11 | 3/4''-16*2 13/32'' UNF |
| 6V1792+1S1860 | TRACK BOLT & NUT | 9.55964E+11 | 3/4''-16*2 7/16'' UNF |
| 1S8804/154-32-11210 | TRACK BOLT | D80A-8 | 3/4''-16*2 31/64'' UNF |
| 7F8619 | TRACK BOLT | 3/4''-16*2 3/4'' UNF | |
| TB3/4*3 | TRACK BOLT & NUT | 3/4''-16*3'' UNF | |
| 9S1837 | TRACK BOLT & NUT | 3/4''-16*3 15/32'' UNF | |
| 6T2162+1S1860 | TRACK BOLT & NUT | 3/4''-16*3 5/8'' UNF | |
| 5A7524+1S1860 | TRACK BOLT & NUT | 3/4''-16*4'' UNF | |
| 9S1838 | TRACK BOLT & NUT | 3/4''-16*4 1/8'' UNF | |
| TB3/4*4 3/4 | TRACK BOLT & NUT | 3/4''-16*4 3/4'' UNF | |
| 7H3608/150-32-21331 | NUT | 3/4''-16UNF | |
| 154-32-21330 | NUT | 3/4''-16UNF | |
| TBNS3/4 | NUT | 3/4''-16UNF | |
| TBNS3/4 | NUT | 3/4''-16UNF | |
| TB7/8*2 17/32 | TRACK BOLT & NUT | 7/8''-14*2 17/32''UNF | |
| 9M7444 | TRACK BOLT | 7/8''-14*2 41/64''UNF | |
| 7H3599+2S2140 | TRACK BOLT & NUT | D8,D8L,D8N,D8H,583,983 | 7/8''-14*2 21/32''UNF |
| 1H4215 | TRACK BOLT | 7/8''-14*2 23/32''UNF | |
| 170-32-11212+170-32-11222 | TRACK BOLT & NUT | 7/8''-14*3''UNF | |
| 7T2748+7G6442 | TRACK BOLT & NUT | 7/8''-14*3 11/32''UNF | |
| 6V1723+7G6442 | TRACK BOLT & NUT | 7/8''-14*3 13/32''UNF | |
| TB7/8*4 27/32 | TRACK BOLT & NUT | 7/8''-14*4 27/32''UNF | |
| TB7/8*5 3/4 | TRACK BOLT & NUT | 7/8''-14*5 3/4''UNF | |
| 7H3609 | NUT | 7/8''-14UNF | |
| 2M5657+1S6421 | TRACK BOLT & NUT | D9,D9E,D9D,D9G,D9H,D9L | 1''-14*2 15/16'' UNF |
| 9M7445 | TRACK BOLT | 1''-14*2 31/32'' UNF | |
| 3T6308+2V0250 | TRACK BOLT & NUT | D9N,594 | 1''-14*3 1/8'' UNF |
| 6V1726+7G0343 | TRACK BOLT & NUT | 1''-14*3 3/16'' UNF | |
| 6T2638+7G0343 | TRACK BOLT & NUT | 245/D9 | 1''-14*3 35/64'' UNF |
| 2M5656 | NUT | 1''-14* UNF | |
| 7T1000+5P8221 | TRACK BOLT & NUT | D10N,D30A.P.Q.S-15, | 1 1/8''*3 25/32'' UNF |
| 5P3868+5P8221 | TRACK BOLT & NUT | D31A.P.Q.S-15 | 1 1/8''*4 13/32'' UNF |
| 101-32-11210 | TRACK BOLT | D20A-3,D21A-3 | M12*1.25*35 |
| 201-32-11210 | TRACK BOLT | D21S-3,D21S-5 | M12*1.25*35 |
| TB12037 | TRACK BOLT & NUT | M12*1.25*37 | |
| 201-32-11210 | TRACK BOLT | D21-3/5 | M12*1.25*39 |
| 106-32-11210 | TRACK BOLT | D20,D21Q,P,PL-5 | M12*1.25*47 |
| 01803-01218 | NUT | M12*1.25 | |
All kinds of track bolts &nuts,plow bolts &nuts,hex bolts &nuts,segment bolts &nuts,screws is available, including those not in the table, please contact us for Product Catalog.
- 24/7 customer support response (including holidays)
- Technical support available anytime
- Free replacements for confirmed quality issues
8t9079,Track Bolts and Nuts,excavator track undercarriage parts,High Quality Plow Segment Bolt,excavator Segment Bolt, excavator Track Bolts and Nuts
