50W 100W Flying Fiber Laser Marking Machine For Stainless Steel / Medical Devices
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
5-7 work day
Brand:
COTAJET
Product Description
50W 100W Flying Fiber Laser Marking Machine For Stainless Steel / Medical Devices
The Fiber Laser Marking Machine is specifically designed for high-precision marking on stainless steel components used in medical devices and aerospace applications.
This advanced fly fiber laser marking system is ideal for:
- Electronic cable marking
- Expiry date marking on various materials including plastic, rubber, metal cans, and foil pouch bags
Key Features
- Non-destructive marking that preserves anti-corrosive properties
- High-contrast anneal style marks
- Permanent, high-resolution identification
- Precision marking without compromising material properties
Product Specifications
| Attribute | Value |
|---|---|
| Material | Laser coder for metal |
| Product ID | CL400B |
| Laser Power | 50W, 100W |
| Marking Speed | ≤12000mm/s |
| Laser wavelength | 10.6um |
| Marking Range | 110X110mm (Standard) Optional: 150X150mm, 300X300mm |
Technical Parameters
| Parameter | 50W | 100W |
|---|---|---|
| Machine Material | All aluminum sandblasting oxidation | |
| Laser Service Life | >100,000 hours | |
| Laser Wavelength | 1064nm | |
| Output Power | ≥54W | ≥110W |
| Marking Speed | ≤12000mm/s | |
| Controller | 10.2 inch touch controller | |
| Cooling System | Air cooling | |
| Focus Lens | 165mm | |
| Minimum Line Width | 0.012mm | |
| Repetition Accuracy | 0.003mm | |
| Marking Range | 110mm*110mm (optional sizes available) | |
Software & System Specifications
- Multilingual support: English, Spanish, German, Chinese, Russian, Arabic
- Multi-user management system
- Linux operating system
- Support for various inkjet modes: Static, analog, encoder
- Power failure data protection
- Overspeed alarm functionality
- Automatic intersection removal
- Supports multiple file formats: BMP/DXF/HPGL/JPEG/PLT
- Barcode support: CODE39, CODE128, CODE126, QR
Electrical & Physical Specifications
- Power Supply: 220V/50HZ
- Power Consumption: 600W
- Net Weight: 38kg
- Dimensions: 530mm × 140mm × 165mm
- Operating Environment: Temperature 0℃－45℃; Humidity ≤95%
