WT2110 WT2110B Mini Digital Coating Thickness Gauge with 0~1500μm Range Color-Screen HD Display and Bluetooth Function
Price:
EXW US$60~US$69
MOQ:
20
Delivery Time:
3-5 working days
Brand:
Wintact,Bestone
Product Description
Applications:
with high-definition display, which can quickly, non-destructively and accurately measure non-magnetic coating thickness on magnetic metal substrates and non-metallic coating thickness measurement on non-magnetic metal substrates. At the same time, it can automatically identify magnetic metal substrate and non-magnetic metal substrate, and is widely used in manufacturing, metal processing industry, chemical industry, commodity inspection and other testing areas. This product is a color-screen portable coating thickness gauge.
Features:
- Menu operation and color-screen HD display.
- Fe (magnetic metal).
- NFe (non-magnetic metal).
- Three calibration modes: basic, offset, zero calibration.
- Metric/imperial unit and storage function.
- Screen rotation, charge protection, multi-interface displays, screen brightness selection.
- Automatic shutdown.
- Bluetooth function (used with APP) (only for WT2110B).
- USB data transfer (use with PC software). (only for WT2110B).
- USB charging function (for WT2110B).
Specification:
| Model | WT2110 | WT2110B |
|---|---|---|
| Measurement range | 0~1500μm/0~59mil/0~1.5mm | 0~1500μm/0~59mil/0~1.5mm |
| Resolution | (0.1μmm(<100μm),1μm(≥100μm))/0.1mil/0.001mm | |
| Measurement error | ≤150μm: ±5μm >150μm: ±(3%H+1μm) |
|
| Min. diameter of magnetic metal substrate | 12mm | |
| Min. thickness of magnetic metal substrate | 0.5mm | |
| Minimum radius of curvature for magnetic convex substrate | 2mm | |
| Minimum radius of curvature for magnetic concave substrate | 11mm | |
| Minimum diameter of non magnetic metal substrate | 50mm | |
| Minimum thickness of non- magnetic metal substrate | 0.5mm | |
| Operating temperature range | 0~40℃ | |
| Work humidity range | 10~95%RH | |
| Power supply | 1000mAh Lithium battery (5V1A power adapter) | |
| Temperature range of operation | 0～40℃ | |
| Dimension | 70.30*38.6*149.59mm | |
| Weight | 108g | |
