China Ht-A2+ Touch Screen Mobile Phone Thermal Imager Portable 3.2 Inch Touch Screen Small Size Easy to Carry for sale

Ht-A2+ Touch Screen Mobile Phone Thermal Imager Portable 3.2 Inch Touch Screen Small Size Easy to Carry

Price Negotiable

Price: 215

MOQ: 1

Delivery Time: Negotiable

Product Description

HT-A2+ Touch Screen Mobile Phone Thermal Imager

Portable 3.2-inch touch screen thermal imager with small size for easy carrying and professional use.

Applications

Infrared thermal imaging cameras are widely used in medical, public security, fire protection, archaeology, transportation, agriculture, and geology. An ideal choice for electricians and maintenance technicians to quickly locate problem areas.

Key Features

Outdoor portable fill light function: Clear thermal imaging with lightweight outdoor design
3 temperature measurement modes: Central point, highest temperature, and lowest temperature tracking
5 color palettes: Rainbow, Iron red, Cool, White hot, Black hot for different scenario requirements
Adjustable emissivity: Configurable from 0.01 to 1.00 (default: 0.95)
LED fill light visible light camera: Captures fine details in dim environments
Imported chips: 12μm/256×192 pixel thermal imaging sensor with NETD<50Mk for high contrast and sharp images
USB charging: 3000mAh large capacity lithium battery with battery status monitoring
Weather resistant: Operating temperature -10°C to 50°C for reliable use in various conditions
Enhanced picture quality: 256×192 high resolution with ≤25Hz frame rate for smooth, delay-free recording

Technical Specifications

Model	HT-A2+
Display Screen	3.2 inch Touch screen
Infrared image resolution	256×192
Focal length	3.2mm
Field angle	56°(H)×42°(V)
Pixel spacing	12μm
IFOV	3.75mrad
Working band	8~14μm
NETD	≤50mk@25°C, @F/1.1
Image frame rate	≤25Hz
Focusing mode	Fixed
Emissivity setting	Adjustable from 0.01 ~ 1.00
Color palette	Rainbow, iron, cold color, white hot, black hot
Temperature measurement model	Center point / Cold and hot spot tracking
LCD resolution	640×480
Image display mode	Infrared light / visible light / infrared and visible lights
Temperature measurement range	-20°C~550°C(-4°F~1022°F)
Measurement accuracy	300°C-500°C: ±4°C; -15°C~300°C: ±2°C or ±2%; -20°C~-15°C: ±4°C

Additional Information

Device storage	eMMC 16GB (available space: 13.9GB)
Picture/Video format	JPG/MP4
Language	Chinese, English, Italian, German
Power supply	Built-in chargeable 3000mAh lithium battery
Power interface	Type-C USB
Automatic power off time	5 minutes/20 minutes/not power off automatically
Work temperature	-10°C~+50°C(14°F~122°F)
Storage temperature	-20°C~+60°C(-4°F~140°F)
Relative humidity	<85%RH (non-condensing)
Product size	140mm×80mm×28mm
Product weight	208g
