FM-204-100K Digital Force Gauge with ±0.5% Accuracy for Peak Value Measurement
Price:
negotiable
MOQ:
2
Delivery Time:
5-8 working days
Brand:
Bestone
Product Description
Digital Force Gauge FM-204-100K
The Digital Force Gauge FM-204-100K is a precision instrument designed for high-accuracy push and pull force testing. This versatile tool finds applications across multiple industries including electronics, automotive parts, construction hardware, textiles, fire safety equipment, lock manufacturing, and scientific research institutions.
Key Features
- High accuracy and resolution for precise measurements
- Digital display eliminates guesswork and reading errors
- Four selectable measurement units: N, kg, lb, g with easy conversion
- Peak value hold function for maximum force recording
- 10-minute auto power off with manual override option
- Dual power options: alkaline batteries or 5V DC power supply
Technical Specifications
| Force Range | ±100 kgf ±980 N ±220 Lbf |
|---|---|
| Resolution | 0.01 kgf 0.1 N 0.1 Lbf |
| Accuracy | ±0.5% FS ±1 Digit |
| Measurement Units | kgf, gf, N, Lbf |
| Measurement States | Peak Value Measurement, Real Time Measurement |
| Display | 2 Reversed 4-Digit LCD |
| Power Management | 10 Minutes Auto Power Off, Manual Power Off |
| Backlight | Blue Backlight |
| Safe Load | 150% FS (Buzzer Alarm Over 110% FS) |
| Power Supply | 2x1.5 AA (UM-3) Battery or 6V DC Power Supply |
| Operating Temperature | 0ºC to 40ºC |
| Operating Humidity | Less than 80% |
| Environmental Requirements | No vibration source or corrosive medium |
| Weight | 390g |
| Dimensions | 211mm x 80mm x 36mm |
Standard Accessories
Digital Force Gauge, Pulling Hook, Flat Tip, Cone Tip, V-shaped Groove Tip, V-shaped Wedge Tip, Manual, Carrying Case
Optional Accessories
Power adapter
