Solar Aftermarket TPMS System Car 4PCS Tire Pressure Monitoring System Automatic Matching
Solar Aftermaket Car Internal External Tire Pressure Monitor Inside Installation 4PCS TPMS Tire Pressure Monitoring System
This is a universal solar internal tire pressure monitoring system. There are 4 pcs internal sensor in the kit. This Solar Tire Pressure Monitoring System (TPMS) uses 4 sensors in your tires to track air pressure and warns you via a sound alarm in LCD display or display if pressure drops significantly (usually 25%) below recommended levels, enhancing safety, fuel efficiency.
And tire life can be prolonged by alerting you to low pressure, leaks, or punctures, with two main types: internal direct (sensors in each wheel) and external (sensors installed on valves). When the light comes on or sound alarm, check tire pressure at a service station.
Features
- Internal sensors with 5 years lifespan
- 433Mhz frequncy
- Automatic matching, no need to change position
- Fast Date update within 4s
- Pressure range: 0-8Bar / 0-116PSI
- Sensor preset in factory
- Self-testing for each power on
- End users can set the threshold of tire pressure
- Convertible pressure unit (PSI / Bar)
- Sleeping mode available, Built-in G-sensor, can be wake up immediately when the car is moving
- Display with visual and audible warning for tire pressure and temperature
- From the car stop to start, Sensor can be wake up in 5s
- High-definition colorful LCD display, simultaneously show 4 tires pressure
- Display can be charged by solar energy or mini USB charging slot
- Display with visual and audible warning for tire pressure and temperature
Technique Specification for Sensor
| Operating frequency | 433.92MHz ± 28KHz |
| Operating voltage: | 2.0~3.3V |
| Operating current: | ≤10mA |
| Static current: | ≤1uA |
| Operating temperature: | -40°C~+125°C |
| Storage temperature: | -40°C~+125°C |
| Battery lifespan: | ≥5years |
| Weight: | 36g ± 1g |
| Battery: | CR2050 |
Technique Specification for LCD Solar Display
| Operating frequency | 433.92MHz±28KHz |
| Operating current: | ≤4mA |
| Static current: | ≤100μA |
| Operating voltage: | 2.6-3.6V |
| Operating temperature: | -40ºC~+85ºC |
| Built-in battery capacity: | 3.2V/500mA |
| Weight: | 67g ± 1g |
Part detail
| Solar Display | 1pc |
| TPMS Sensor | 4pcs |
| Accessary bag | 1pc |
| Manual | 1pc |
External sensors for optional. Battery lifespan is more than 1 year
FAQ
Q1: What is the frequency and application?
A1: Sensor frequency is 433Mhz. It used for aftermaket.
Q2: What's your package?
A2: Our standard package is carton for 20 sets. Gross wight is 11KG.
Q3: What is your MOQ?
A3: 100 sets.Sample is available.
Q4: Do you offer OEM and ODM service?
A4: Yes, OEM and ODM service available.
Q5: When is the lead time?
A5:1-10 working days upon your order of products.
Q6: What about quality warranty?
A6: 1 year.
Q7: What is Price Term?
A7: EXW. FOB Shenzhen, CIF accepted.
Q8: How about Payment Term?
A8: TT 50% in advance, balance before shipment; L/C, Paypal, Western Union.
Q9: What about shipment?
A9: DHL, EMS, FedEx, UPS, TNT Express; By air or by sea
Q10: After-sales and Refund Policy?
A10: If there is any fault items, pls kindly send us proof, such as photo or video. We will try our best to solve this online first. If still cannot solve, pls send this back to us for repair. The new one will be send to you after problem confirmed.
