50 Ohm 4.3-10 DIN Connector Male Plug with Nickel Plated Brass and PTFE Insulator for LMR400 Cable
4.3-10 RF connector is a 50Ω miniaturized RF coaxial connector, specifically designed to replace the traditional 7/16 DIN connector. This connector is a core connection component in the communication field and is widely used in macro base stations, small base stations, indoor wireless systems, and wireless remote control devices (RRU). It is compatible with both active and passive antennas, splitters, filter systems and other devices simultaneously. In addition, it is also widely applied in scenarios such as multi-band distributed antenna systems (DAS) and panel blind insertion matching. By leveraging the advantage of miniaturization, it enhances the flexibility of equipment layout and facilitates the integrated design of communication equipment.
|
Product model
|
4.3-10-C-J-7 |
Dielectric constant
|
≥5000MΩ
|
|
Characteristic impedance
|
50 ohm |
Body material
|
Nickel-plated brass |
|
Frequency range
|
DC-6GHz |
Central conductor
|
Gold-plated brass |
|
Voltage standing wave ratio
|
≤1.25 |
Insulator material
|
PTFE |
|
Medium pressure resistance
|
≥2500V RMS ,50hz, at sea level |
Durability
|
≥500 Cycles |
|
Contact resistance
|
Center contact:≤1mΩ Outer contact:≤1mΩ |
Temperature range
|
-45℃~+125℃ |
- Standard export carton
- As per customized specifications such as logo or others According to customers' requirements
- Delivery time:Within 24 hours for stocks, 3-4 weeks for mass production orders. (based on different quantities,ODM, etc.)
