MIL-DTL-5015 Circular Connector MS3106A-22-22P 4-Pin Male Plug with 1500V Withstand Voltage and Aluminum Alloy Body
Price:
$19.80-$28.50(Depending on the quantity)
MOQ:
20 pcs
Delivery Time:
5-8 Days
Brand:
ZSX
Product Description
MIL-DTL-5015 Circular Connector MS3106A-22-22P 4-Pin Flanged Male Plug Welded Type Connector
MIL-DTL-5015 Circular Connector MS3106A-22-22P 4-Pin Flanged Male Plug Welded Type Connector. MS3106A-22-22P is a Aeronautics and Astronautics circular connector complying with MIL-DTL-5015, designed as a straight plug with 4 pins (male), solder termination, and threaded coupling. It features a 22-size aluminum alloy shell, with the shell plated with olive drab chromate over cadmium and copper alloy contacts plated with silver for excellent corrosion resistance and electrical conductivity. The model is decoded as follows: MS3106 = straight plug, A = solid backshell (general non-sealed type), 22 = shell size, 22 = insert arrangement (4-core), P = male plug (pins). Widely used in defense, Aeronautics and Astronautics, and industrial fields, it is equivalent to Amphenol industrial specifications, with a rated current matching #8 contact standards, suitable for high-reliability signal and power transmission. Its matching socket is MS3102A-22-22S.
Product Performance Specifications
| Product Model | MS3112E14-4P | Contact Material | Gold plating of copper alloy |
|---|---|---|---|
| Shell Material | Aluminum alloy | Insulation Resistance | ≥5000MΩ |
| Vibration | 10Hz~2000Hz 147m/s² | Working Voltage | 600V |
| Insulator | Thermosetting plastics | Mechanical Life | 500 times |
| Impact | 980m/s² | Relative Humidity | When the temperature is 40±2℃, it is 90% to 95% |
| Collision | Acceleration 392m/s² | Withstand Voltage | 1500V |
| Working Temperature | -55℃ ~ +125℃ | Working Current | 30A |
