MS3106A-22-22S Aeronautics and Astronautics Circular Connector with Aluminum Alloy Shell, 1500V Withstand Voltage, and -55℃ to +125℃ Working Temperature
The MS3106A-22-22S is a high-reliability Aeronautics and Astronautics circular socket connector complying with the MIL-DTL-5015 standard, featuring a threaded locking design and solder termination for easy installation. As a specialized socket connector, it adopts a high-quality aluminum alloy shell with anti-corrosion plating, which enhances anti-interference performance and ensures stable operation in harsh environments such as high temperature, vibration and impact. With a compact structure and reasonable insert arrangement, it is perfectly matched with the corresponding plug, suitable for high-density signal and power transmission in Aeronautics and Astronautics equipment, aerospace, industrial control and other fields. It supports bulk ordering and provides professional technical support, making it an ideal choice for high-demand connection scenarios.
| Product Model | MS3106A-22-22S | Contact Piece | Gold Plating of Copper Alloy |
|---|---|---|---|
| Shell Material | Aluminum Alloy | Insulation Resistance | ≥5000MΩ |
| Vibration | 10Hz~2000Hz 147m/s² | Working Voltage | 600V |
| Insulator | Thermosetting Plastics | Mechanical Life | 500 Times |
| Impact | 980m/s² | Relative Humidity | When the temperature is 40±2℃, it is 90% to 95% |
| Collision | Acceleration 392m/s² | Withstand Voltage | 1500V |
| Working Temperature | -55℃ ~ +125℃ | Working Current | 25A |
- Standard export carton
- Customized specifications such as logo or others according to customers' requirements
- Delivery time: Within 24 hours for stocks, 3-4 weeks for mass production orders (based on different quantities, ODM, etc.)
