Heavy Duty GMB1713 CNC Gantry Milling Machine 4 Axis Machining Center 1200x1600
The GM series CNC gantry machining center is a gantry frame fixed, worktable moving structure, mainly composed of worktable, bed, column, crossbeam, slide, hydraulic system, lubrication system, cooling and filtration system, chip removal device, rotary operation panel and electronic control system.
| MODEL | UNIT | GMB1713 | ||
| Worktable | Table size | mm | 1200*1600 | |
| Distance between two vertical columns | mm | 1300 | ||
| Max. Table load | kg | 5000 | ||
| T-slotted size | mm | 22*7 | ||
| Processing range | Max. Travel of workbench-X axis | mm | 1700 | |
| Max. Travel of sliding saddle-Y axis | mm | 1300 | ||
| Max. Spindle travel-Z axis | mm | 800 | ||
| Distance from spindle end face to worktable | Max | mm | 950 | |
| Min | mm | 150 | ||
| Spindle | Bore-hole(7:24) | / | BT40-Φ150 | |
| Revolution range | r/min | 40-8000 | ||
| Main motor model | N.m | D15 | ||
| Max. Power of motor | kw | 15 | ||
| Four-axis | Model | / | B320 | |
| Dimension of worktable | mm | 320 | ||
| Center height | mm | 210 | ||
| Reduction ratio | / | 1:60 | ||
| Motor torque | Nm | 12 | ||
| Segmentation accuracy | " | ±15 | ||
| Repeat positioning accuracy | " | 6 | ||
| Bearing | Vertical | kg | 180 | |
| Horizontal | kg | 350 | ||
| Tool magazine | Capacity | T | 24 | |
| Max. Tool weight | kg | 8 | ||
| Max. Tool diameter(full blade) | mm | Φ78 | ||
| Max. Tool diameter(free face blade) | mm | Φ112 | ||
| Max. Tool length | mm | 300 | ||
| Tool change time | s | 2.5 | ||
| Feed | Range of cutting feed rate | mm/min | 1-10000 | |
| Fast moving | X axis | m/min | 20 | |
| Y axis | m/min | 20 | ||
| Z axis | m/min | 16 | ||
| Feed motor | X axis | KW/NM | 3/22 | |
| Y axis | KW/NM | 3/22 | ||
| Z axis | KW/NM | 3/22 | ||
| Three-axis screw | X axis | mm | Φ50-12 | |
| Y axis | mm | Φ40-12 | ||
| Z axis | mm | Φ40-12 | ||
| Three-axis linear guide rail | X axis | mm | 2-45 | |
| Y axis | mm | 2-45 | ||
| Z axis | mm | 4-45 | ||
| Machine tool positioning accuracy | X axis | Execution standards: JB/T8771.4-1998 | mm | 0.022 |
| Y axis | mm | 0.018 | ||
| Z axis | mm | 0.015 | ||
| Repeat positioning accuracy | X axis | Execution standards: JB/T8771.4-1998 | mm | 0.012 |
| Y axis | mm | 0.010 | ||
| Z axis | mm | 0.010 | ||
| Wright | kg | 9600 | ||
| Total electrical capacity | KVA | 48 | ||
| Dimension(L*W*H) | mm | 6130*2670*3280 | ||
The GM series CNC gantry machining center has a strong rigidity of basic frame, symmetrical structure, strong stability, and strong rigidity of the whole machine through strengthening the reinforcement structure and reasonable layout. It has multiple processing functions such as milling, boring, drilling (expansion, reaming), tapping, etc., and is commonly used in various mechanical processing fields such as automobiles, molds, aerospace, packaging, hardware, etc.
This machine is used in CNC milling, boring, drilling, tapping, processing of steel, cast steel, cast iron etc.. Machine tool accessory head to realize the of all kinds of plate, plate, shell and mould for complex parts in a fixture in complete drilling,milling, boring, reaming, reaming, tapping a variety of processes. It can be used for small batch spare parts, processing and manufacturing, of complex, high precision parts processing more show its superiority, also can compose the automatic production line for mass production, to ensure the parts of product quality and efficient production.
Suitable for rough and precision machining of automotive components auch as wheel hubs and discs. The machine tool adopts a roller type linear slide rail. Has ultra-high rigidity and overload capacity.
