VMC1160 Heavy Duty CNC Vertical Machining Center 3 Axis CNC Milling Machine for Metal
Price:
20800-28500
MOQ:
1
Delivery Time:
30 working days
Brand:
Matsumoto
Product Description
VMC1160 Heavy Duty CNC Vertical Machining Center 3 Axis CNC Milling Machine for Metal
Description:
The VMC1160 is a high-performance vertical CNC machining center, designed for precision and versatility in medium to large-scale metalworking.
| Specifications | Units | VMC1160 |
| Table size | mm | 1200*600 |
| Max.table load | kg | 800 |
| T slot | / | 5-18*100 |
| X axis travel | mm | 1100 |
| Y axis travel | mm | 600 |
| Z axis travel | mm | 600 |
| Distance between spindle center and column surface | mm | 600 |
| Distance between spindle nose and table surface | mm | 120-720 |
| Max. spindle speed | r/min | 8000(10000 optional) |
| Spindle taper | - | BT40 |
| Spindle drive type | - | Belt drive |
| spindle motor power | kw | 11 |
| X/Y/Z axis rapid traverse | m/min | 36/36/24 |
| X/Y/Z guide rail form | / | 3 axis linear guide rail |
| Automatic tools changer | - | 24 arm ATC |
| Max.tool weight | kg | 7 |
| Tools Diameter/Length | mm | 78/300 |
| Tool change time | s | 7/2.5 |
| Position accuracy | mm | ±0.005 |
| Repeat positioning accuracy | mm | ±0.003 |
| Machine dimension | mm | 3400*2480*2960 |
| Machine weight | kg | 7300 |
Applications:
Ideal for complex, multi-operation parts in diverse industries:
- Mold & Die: Injection molds, die-casting dies, forging dies.
- Automotive: Engine blocks, cylinder heads, transmission parts.
- Aerospace: Structural components, turbine parts, high-precision fittings.
- General Engineering: Housings, plates, brackets, jigs & fixtures.
- Energy & Hydraulics: Pump bodies, valve parts, heavy machinery components.
- Prototyping & Batch Production: Single prototypes to medium-volume production.
Materials: Steel, stainless steel, cast iron, aluminum, titanium, copper, brass.
