TCK80Y Heavy Duty Slant Bed CNC Lathe Metal Processing CNC Turning and Milling Machine

Price Negotiable

Price: 32500-40000

MOQ: 1

Delivery Time: 30 working days

Brand: Matsumoto

Product Description

TCK80Y Heavy Duty Slant Bed CNC Lathe Metal Processing CNC Turning and Milling Machine

Description:

TCK80Y CNC Turning-Milling Machine is a heavy-duty, high-precision slant-bed CNC lathe with integrated Y-axis milling capability, designed for complex, multi-process machining in a single setup.

SPECIFICATIONS	Units	TCK80Y
Swing over bed	mm	800
Max. workpiece length	mm	1000/1500/2000/3000
Max. cutting diameter	mm	600
Spindle bore	mm	80
Spindle nose type	-	A2-11(A2-8)
Spindle speed steps	-	Stepless
Spindle speed range	rpm	2000(3000)
Chuck	-	12'' Hollow hydraulic chuck
X axis travel	mm	350
Y axis travel	mm	±50
Z axis travel	mm	900/1400/1900/2900
X axis rapid traverse	mm/min	12
Y axis rapid traverse	mm/min	12
Z axis rapid traverse	mm/min	16
Main motor power	kw	18.5(Opt.37)
Turret type		12 Position Live turret
Turret Model		BMT65-ER32
Tailstock quill taper	-	MT6
Tailstock base travel	mm	900/1400/1900/2900
Machine weight	kg	7000/8000/9000/11000

Key Features:

30° Slant Bed Structure: One-piece cast iron bed offering superior rigidity, stability, and efficient chip removal.

Y-axis Function: Enables off-center milling, drilling, and tapping operations on cylindrical surfaces.

Core Capabilities:

Turning: External / internal diameters, faces, tapers, contours, and threads.
Milling: Keyways, flats, polygons, grooves, and profiles on the circumference or face.
Drilling & Tapping: Radial and axial holes, cross holes, and threaded holes.
