1.5mm-10mm Electrical Solar Cable 800V 1800V Photovoltaic Solar Power Cables
Price:
0.12-0.35USD
MOQ:
100m
Delivery Time:
3-7
Brand:
JinHong
Product Description
PV1-F Single-Core Photovoltaic Cable
PV1-F is a Single-Core Photovoltaic Cable specifically engineered for solar power systems, delivering exceptional weather resistance, UV protection, and electrical performance for DC side connections in photovoltaic installations.
Cable Designation Breakdown
- PV: Photovoltaic
- 1: Single-Core
- F: Flexible (Fine-Stranded Copper Conductor)
Primary Applications
- Solar Panel Arrays: Interconnections between PV modules
- DC Wiring: Connections from solar panels to inverters or combiner boxes
- Outdoor Installations: Rooftop PV systems, solar farms, and ground-mounted installations
- Renewable Energy Systems: Battery storage connections and charge controllers
Key Advantages
- Solar-Optimized: Specifically engineered for PV systems with high UV and weather resistance
- Flexibility: Easy installation around PV modules and in tight spaces
- Durability: Tinned copper conductor resists corrosion in humid environments
- Safety: Flame-retardant and halogen-free options reduce fire risks
PV1-F is the industry standard for solar DC wiring. For higher voltage requirements in utility-scale projects, consider PV1-F1.8 kV variants. Custom colors and conductor sizes are available. Consult technical datasheets for system-specific recommendations.
Technical Specifications
| Nominal Cross-Section (mm²) | Conductor Structure (n/mm) | Max DC Resistance at 20°C (Ω/km) | Reference Conductor Diameter (mm) | Reference Cable Diameter (mm) | Reference Cable Weight (kg/km) |
|---|---|---|---|---|---|
| 1.5 | 30/0.25 | 13.7 | 1.6 | 5.1 | 40.1 |
| 2.5 | 49/0.25 | 8.21 | 2.0 | 5.5 | 50.9 |
| 4 | 56/0.30 | 5.09 | 2.6 | 6.2 | 70.3 |
| 6 | 84/0.30 | 3.39 | 3.5 | 7.1 | 94.6 |
| 10 | 77/0.41 | 1.95 | 4.6 | 9.4 | 159.1 |
| 16 | 119/0.41 | 1.24 | 5.7 | 10.9 | 225.7 |
| 25 | 189/0.41 | 0.795 | 7.2 | 12.6 | 325.8 |
| 35 | 259/0.41 | 0.565 | 8.2 | 13.8 | 421.8 |
Frequently Asked Questions
What does PV1-F stand for?
It is a single-core, flexible cable designed specifically for photovoltaic applications.
What is the primary application of PV1-F cable?
It is used exclusively for the DC side of photovoltaic systems to interconnect solar panels and connect them to inverters or combiner boxes.
What are its key environmental resistance features?
PV1-F is engineered for harsh, long-term outdoor exposure:
- UV & Ozone Resistance: Withstands direct sunlight for 20+ years without cracking
- Wide Temperature Range: Typically -40°C to +90°C (or up to 120°C short-term)
- Weather & Moisture Resistance: Performs in rain, snow, and high humidity
- Chemical Resistance: Resists acids, alkalis, and pollution commonly found in industrial/agricultural environments
What are its electrical specifications?
- Voltage Rating: DC 1.5 kV (standard for PV systems up to 1500V DC)
- Conductor: Tinned, fine-stranded copper for flexibility and corrosion resistance
- Insulation/Sheath: Cross-linked polyolefin (XLPO) or similar halogen-free material
- Polarity Identification: Available in standard colors (Red for Positive, Black for Negative)
What safety and performance standards does it meet?
PV1-F complies with stringent international PV cable standards:
- Europe: TÜV 2 PfG 1169 / EN 50618 (The most recognized standard)
- International: IEC 62930
- North America: UL 4703 (Sunlight Resistant PV Wire)
Can ordinary cable (like H07RN-F) be used instead?
Not recommended. Ordinary cables are not designed for continuous high DC voltage stress, decades of direct UV exposure, or the specific thermal cycling of PV systems. Using non-PV cable voids system warranties and poses safety risks.
Where exactly is PV1-F installed in a PV system?
- Module Interconnections: Between solar panels in a string
- String to Combiner Box: Connecting series strings to a combiner box
- DC Main Runs: From combiner boxes to the central inverter(s)
- Suitable for fixed installation on mounting structures, in cable trays, or for free movement within bend radius limits
What are important installation guidelines?
- Bending Radius: Minimum 4 x cable diameter (very flexible)
- Installation Temperature: As low as -25°C to -40°C (prevents insulation damage)
- Connection: Must use PV-specific connectors that are weatherproof and compatible with the cable's outer diameter
- Securing: Use UV-resistant cable ties or clamps
What are common variants or similar designations?
- PV1-F 1.8kV: For higher system voltages
- H1Z2Z2-K (or PV-Wire): Older or alternative designations to the same core standards
- Multi-core versions exist for specific applications
Why is PV1-F a mandatory choice for solar projects?
It is a critical, system-longevity component that ensures:
- Safety: Reliable insulation under DC stress and fire conditions
- Durability: 25+ year service life matching solar panels
- Performance: Maintains conductivity and insulation integrity over decades
- Warranty Compliance: Required by panel/inverter manufacturers and insurance providers
