Outdoor IP67 Lightning Strike Counter 500A-100kA 5 Year Battery Surge Recorder
| Product Features |
| ● Wide range of counting current, capable of monitoring various lightning strike waveforms |
| ● Built in large capacity battery, no external power supply required |
| ● High protection level, up to IP67 |
| ● Patented technology with reliable performance |
| ● Suitable for counting and monitoring the lightning current and surge current in power or grounding lines. |
Product Specification
| Standards | IEC 62561-6 |
| Models | LSC-500 |
| Pulse current collection method | Built in driver circuit and sensor |
| Counter built-in battery life | 5 years |
| Counter built-in battery type | lithium battery,CR 14250 |
| Counter built-in battery capacity | 1000mA/H |
| Maximum Count Digits | 9999 9999 |
| Minimum count induced current Itc | 500A(8/20μs),1kA(10/350μs) |
| Installation method | Can be fixed on flat steel, flat copper, cables, and down conductors |
Mechanical parameters
| Installation capacity | Wire cross-sectional area:10-90mm²
Copper bar cross-sectional area:≤4*40mm
|
| Size | 110mmx80mmx80mm(Without adjustable bracket) |
| Material |
Housing:ABS+PC Bracket and screws:SUS 304
|
| Installation location | Outdoor,Indoor |
| Shell protection rating | IP67 |
| Temperature range | -20℃…+80℃ |
| Humidity range | Relative humidity≤95% |
Notices
1.The counter is powered by a built-in lithium battery; avoid disassembling the housing to prevent battery damage.
2.Select the appropriate installation method (flat steel, cable, etc.) based on the monitored object.
3.Ensure the installation bracket is securely fixed to withstand wind and vibration.
4.The counter has IP67 protection, but avoid prolonged immersion in water.
5.The counting range is 0~9999; reset the count after reaching the maximum to continue monitoring.
6.Store unused counters in a dry environment to extend battery life.
FAQ
Q1: What is the battery life of the product?
A1: It uses a high-capacity lithium battery with a service life of 5 years under normal conditions.
Q2: What protection level does it have?
A2: It has an IP67 protection level, making it dustproof and waterproof for outdoor use.
Q3: What current range does it support?
A3: It supports 500A~100kA (8/20μs) and 1kA~100kA (10/350μs) induced currents.
Q4: Can it be installed outdoors?
A4: Yes, the IP67 protection level and corrosion-resistant materials make it suitable for outdoor installation.
Q5: Does it require external power supply?
A5: No, it is powered by a built-in lithium battery, eliminating the need for external power.
