Product Overview

The 220N/NS-Z100(S) Stepping/Servo Series Multi-Application Platform is a versatile, industrial-grade desktop XYZ motion system engineered for precision automation tasks across diverse manufacturing and research environments. Designed and manufactured by Large Auto Tech, this platform delivers exceptional accuracy, stability, and scalability—making it the ideal foundation for automated dispensing, soldering, screw fastening, inspection, and other multi-process applications.

With both stepper motor + timing belt drive and servo motor + ball screw drive configurations available, the Z100(S) series adapts to your specific performance, budget, and application needs. Its compact, rigid aluminum frame and modular design ensure seamless integration into small-scale production lines, lab setups, or custom automation workflows.

Servo Version (NS-Z100S)

• High-Precision Motion: XYZ axes driven by high-performance servo motors paired with precision ball screws, delivering micron-level accuracy.
• Enhanced Load Capacity: Supports heavier tooling and payloads without compromising positional repeatability.
• Superior Stability: Smooth, vibration-free operation at variable speeds, ideal for high-tolerance processes.
• Expanded Compatibility: Supports advanced feedback systems, closed-loop control, and integration with vision systems.

Stepper Version (220N-Z100)

• Cost-Effective Precision: Stepper motor + timing belt drive system offers reliable performance for standard automation tasks.
• Flexible Expansion: Rich modular interface supports add-ons like dispensers, soldering irons, and screwdriver heads.
• User-Friendly Operation: Simple handheld controller with intuitive programming for quick setup and recipe management.
• Proven Durability: Low-maintenance design with linear guides for consistent performance in high-cycle environments.

Shared Platform Benefits

• Rigid Construction: Heavy-duty aluminum alloy frame ensures long-term stability and minimal deflection under load.
• Modular Configuration: Supports quick tool swaps to adapt to multiple processes (dispensing, soldering, fastening, etc.).
• Universal Power Supply: Equipped with Taiwan Mean Well power supply for stable, reliable operation worldwide.
• Safety Features: Emergency stop button, overload protection, and enclosed wiring for operator safety.

Applications

The 220N/NS-Z100(S) platform is widely adopted across industries for:

• 3C Electronics: PCB dispensing, component soldering, screw fastening, and camera module assembly.
• Automotive Electronics: Sensor sealing, wire harness potting, and control unit testing.
• Medical Devices: Precision dispensing for catheters, surgical tools, and diagnostic equipment.
• Semiconductor Packaging: Underfill dispensing, die attach, and encapsulation processes.
• Lab Automation: Liquid handling, sample processing, and educational research setups.
• General Manufacturing: Spray coating, laser marking, and quality inspection workflows.

Brand Customers & Case Studies

Xiamen Large Automation’s 220N/NS-Z100(S) series is trusted by leading manufacturers and research institutions globally, including:

• Top-tier 3C Electronics OEMs: Deployed for high-volume smartphone and TWS earphone assembly lines, achieving ±0.02mm repeatability in adhesive dispensing processes.
• Automotive Component Suppliers: Integrated into production lines for ECUs and sensors, ensuring consistent potting quality under harsh environmental conditions.
• University Research Labs: Used for prototyping microfluidic devices and automated testing systems, leveraging the platform’s open architecture for custom experiments.
• Medical Device Manufacturers: Validated for ISO 13485-compliant assembly processes, supporting precise adhesive application for sterile medical tools.

Frequently Asked Questions (FAQ)

Q1: What is the difference between the stepper (220N) and servo (NS) versions?

A: The stepper version is ideal for standard, high-volume tasks with moderate accuracy requirements, offering a cost-effective solution with reliable performance. The servo version uses closed-loop control and ball screws for higher precision, faster response, and heavier load capacity, making it suitable for complex, high-tolerance processes like semiconductor packaging.

Q2: Can the platform be customized for specific applications?

A: Yes! We offer custom modifications including expanded travel ranges, specialized tooling mounts, vision system integration, and communication protocol adjustments to meet unique process requirements. Contact our engineering team to discuss your customization needs.

Q3: What is the repeatability of the platform?

A: The servo version delivers repeatability up to ±0.01mm, while the stepper version maintains ±0.02mm repeatability, ensuring consistent performance across production runs.

Q4: How long does setup and programming take?

A: The handheld controller features a user-friendly teach pendant that allows operators to program motion paths in minutes. Basic dispensing or soldering recipes can be created in under 30 minutes, with no advanced coding required.

Q5: Does Large Auto Tech provide after-sales support?

A: Yes! We offer comprehensive technical support including installation guidance, training videos, remote troubleshooting, and on-site maintenance services for customers worldwide. All platforms come with a 12-month warranty.

Contact Us

Ready to integrate the 220N/NS-Z100(S) Multi-Application Platform into your workflow?
Contact Large Auto Tech today to request a quote, discuss customization options, or schedule a live demo.
