AZL8 Rated residual action current 0.03A,0.1A,0.3A  IEC/EN 61008-1

The AZL8 Residual Current Operated Circuit Breaker is designed for AC circuits with 50/60Hz frequency, rated voltage up to 415V, and rated current up to 63A. When electric shock to a person occurs or when grid leakage current exceeds preset values, the circuit breaker can rapidly cut off the fault power supply within an extremely short time to protect personal safety and electrical equipment. It may also serve for infrequent switching operations of circuits under normal conditions.

RoHS 2.0 compliant

Double busbar wiring function

Wiring Capacity1-35mm²
