AZL9-EV Rated residual action current 0.03A,0.1A,0.3A IEC/EN 61008-1,IEC/EN 62955

AZL9-EV residual current operated circuit breaker is suitable for AC 50/60Hz, rated voltage two poles 240V, four poles 415V, and rated current up to 100A lines. Used to detect AC leakage, pulsating DC leakage, composite wave leakage, and high-frequency leakage up to 1kHz, while disconnecting or triggering the disconnection of electric vehicle charging when a smooth DC residual current greater than or equal to 6mA is detected. When a person is electrocuted or the leakage current of the power grid exceeds the specified value, the circuit breaker can quickly cut off the faulty power supply in a very short time, protecting the safety of people and electrical equipment.

It can also be used for infrequent on/off operations of the line under normal conditions.

This circuit breaker is suitable for various applications, including industrial,commercial, high-rise buildings, and residential environments.

Equipped with AC leakage, pulsating DC leakage, smooth DC leakage, composite wave leakage, and high-frequency leakage protection devices up to 1kHz - with complete protection functions.

A protective device designed specifically for electric vehicles and charging facilities that can detect smooth DC residual current greater than or equal to 6mA.

Compliant with environmental RoHS 2.0.

Double busbar wiring function.

The product has a leakage fault indicator.
