SCM120A Pro Hose Assembly Equipment Professional Hydraulic Crimper Machine
Price:
US$4,100.00-5,700.00
MOQ:
1 Piece (MOQ)
Delivery Time:
30 days
Brand:
DME&JDE
Product Description
SCM120A Pro Hose Assembly Equipment | Professional Hydraulic Crimper Machine
Hose Assembly Equipment Product Name
DME&JDE SCM120A-Pro hydraulic hose crimping machine is an flexible and multi-functional design. Compact design and slim structure conforms to rgonomics and smart control system make it high user-friendliness. It is applicable for crimping of 4 or 6 spiral wires reinforcement hoses up to 2-1/2 inches diameters.
It is also an innovative design. Bright colors, lights designs as well as logo and model display will redefine the crimping machine and will lead a fashion way.
| Crimping Machine Technical Data | |
| Crimp head material | Forge steel |
| Crimp range | 1/4" to 2-1/2" |
| Max. opening without dies | 122mm |
| Max. die opening | 28mm |
| Motor & Voltage | 3 kW / 380 V |
| Cycle time | 7 seconds |
| Oil tank volume | 65 L |
| Control | Number control |
| Foot pedal | Included |
| Noise level | 69dB |
| Die sets | 12 sets |
| L × W × H | 820 × 615.67 × 1200 mm |
| High Pressure Dies Specification | ||||
| Number | Die No. | Crimp Range (mm) | D (mm ) | L (mm) |
|---|---|---|---|---|
| 1 | 14 | 14-16 | 14 | 65 |
| 2 | 16 | 16-19 | 16 | 65 |
| 3 | 19 | 19-22 | 19 | 65 |
| 4 | 22 | 22-26 | 22 | 65 |
| 5 | 26 | 26-30 | 26 | 65 |
| 6 | 30 | 30-34 | 30 | 65 |
| 7 | 34 | 34-39 | 34 | 70 |
| 8 | 39 | 39-45 | 39 | 70 |
| 9 | 45 | 45-51 | 45 | 80 |
| 10 | 51 | 51-57 | 51 | 80 |
| 11 | 57 | 57-63 | 57 | 90 |
| 12 | 63 | 63-69 | 63 | 90 |
