Metric Male 60°Cone Straight Hydraulic Hose Fittings And Adapters DABPM1521
DABPM1521 Straight Connector BSPP Male 60° Cone-Metric Male 60°Cone
Straight Connector product introduction
DABPM1521 is a straight hydraulic adaptor designed for reliable connection between BSPP and metric hydraulic systems. It adopts a male-to-male structure with 60° cone ends on both sides, matched with ED ring sealing to ensure stable and leak‑proof performance under high pressure and vibration. This adaptor follows BSP standard and is manufactured with high‑quality materials, featuring good pressure resistance, durability and long service life. Its straight design helps maintain smooth fluid flow and makes installation and pipeline layout more convenient. It is widely used in industrial hydraulic systems, construction machinery, agricultural equipment and mobile hydraulic units, providing stable and efficient connection for various hydraulic pipelines.
Straight Connector product spcification
| Part Number | F1 (Thread) | F2 (Thread) | C1 | C2 | D1 | D2 | L | S |
|---|---|---|---|---|---|---|---|---|
| - | BSPP | Metric | mm | mm | mm | mm | mm | mm |
| DABPM1521-0414 | 1/4"-19 | M14X1.5 | 11.00 | 12.00 | 4.70 | 6.00 | 32.50 | 19.00 |
| DABPM1521-0418 | 1/4"-19 | M18X1.5 | 11.00 | 12.00 | 4.70 | 9.00 | 33.00 | 24.00 |
Straight Connector product advantage
The DABPM1521 straight hydraulic adaptor is engineered to bridge BSPP and metric hydraulic systems, making it an essential component across a wide range of industrial and mobile hydraulic applications. It is ideally suited for construction machinery such as excavators, cranes, and loaders, where reliable cross-thread connections are critical to withstand heavy loads and continuous vibration. In agricultural equipment, it ensures stable fluid transmission between tractors, harvesters, and other farm machinery, supporting efficient field operations. Additionally, this adaptor is widely used in industrial hydraulic power units, manufacturing plant pipelines, and mobile hydraulic systems, providing a secure, leak-proof link that maintains consistent performance under fluctuating pressures and harsh working conditions, ultimately enhancing the reliability and longevity of the entire hydraulic circuit.
