DME&JDE Hose-Crimper 32-Pro Machine For Large & Irregular Shape Pipes
Hose-Crimper product introduction
DME&JDE Hose-Crimper 32-Pro is a versatile and flexible hydraulic hose crimper machine. Its compact design and slim structure conform to ergonomic principles, and its intelligent control system significantly enhances user-friendliness. This machine is suitable for crimping standard sizes ranging from 14mm to 75mm (*Four steel wires spiral 4SH 2’'),and use a Additional purchase of Die Size:10mm-87mm (*Six steel wires sprial R15 2”). Furthermore, this crimping machine features an innovative design with vibrant colors, unique openwork design, and clear logos and model displays, redefining traditional crimping machines and pioneering a new fashion trend.
Hose-Crimper specification
| Crimp head material | High strength forge steel © "German Industry 4.0" |
| Crimping Diameter Range | 10mm-87mm (*Special sizes can be customized) |
| Capacity of Crimper | 1. Standard Crimper Size:14mm-75mm (*Four steel wires sprial 4SH 2”) 2. Use a Additional purchase of Die Size:10mm-87mm (*Six steel wires sprial R15 2”) |
| Max Opening | 33 mm |
| Max opening without dies | 33 mm + 99 mm = 132 mm |
| Pump flow rate | 12 L/min |
| Max Pressure | 275 bar |
| Crimping Force | 2000 kN |
| Motor power | 4000 W |
| Theoretical Production Capacity | 850 times per hour |
| Speed of Master Dies Closing/open | 2.7 mm/s |
| Sound Pressure Level | 71 dB(A) [Reference target: ISO 45001] |
| Oil tank volume | 55 L |
| Oil quantity/ type | 50 L Recommended : Winter: YB-N32 [HM 32] Summer: YB-N46 [HM46] |
| Enclosure Class | IP 54 |
| Weight | 260 kg (Excluding Oil) |
| Size:Length * width * height | 710 * 500 * 1350 mm |
| Foot pedal / switch | Included [Reference target: ISO 45001] |
| Number | Die No. | Crimp Range (mm) | D (mm ) | L (mm) |
|---|---|---|---|---|
| 1 | 10 | 10-12【Additional purchase】 | 10 | 55 |
| 2 | 12 | 12-14【Additional purchase】 | 12 | 55 |
| 3 | 14 | 14-16 | 14 | 55 |
| 4 | 16 | 16-19 | 16 | 55 |
| 5 | 19 | 19-22 | 19 | 55 |
| 6 | 22 | 22-26 | 22 | 70 |
| 7 | 26 | 26-30 | 26 | 70 |
| 8 | 30 | 30-34 | 30 | 70 |
| 9 | 34 | 34-39 | 34 | 75 |
| 10 | 39 | 39-45 | 39 | 75 |
| 11 | 45 | 45-51 | 45 | 90 |
| 12 | 51 | 51-57 | 51 | 90 |
| 13 | 57 | 57-63 | 57 | 100 |
| 14 | 63 | 63-69 | 63 | 110 |
| 15 | 69 | 69-75 | 69 | 110 |
| 16 | 74 | 74-80【Additional purchase】 | 74 | 110 |
| 17 | 78 | 78-87【Additional purchase】 | 78 | 110 |
Hose-Crimper capacity
With years of experience, DME&JDE is always developing and continuing to grow. Visit the company and the workshop to learn more about the spirit, culture and strength of DME&JDE. Advanced equipment and strict working principles ensure that hydraulic hoses, hydraulic fluid connector fittings and hose assemblies meet or exceed international standards.
