Intelligent Hose Crimper 32-Plus Hydraulic Hose Machine For Large & Irregular Shape Pipes
DME&JDE Hose-Crimper 32-Plus Machine for Large & Irregular Shape Pipes
Hose-Crimper product introduction
DME&JDE Hose-Crimper 32-Plus is a versatile and flexible hydraulic hose crimper machine. Its compact design and slim structure conform to ergonomic principles, and its intelligent control system significantly enhances user-friendliness. This machine is suitable for crimping standard sizes ranging from 14mm to 75mm (*Four steel wires spiral 4SH 2’'),and use a Additional purchase of Die Size:10mm-87mm (*Six steel wires sprial R15 2”). Furthermore, this crimping machine features an innovative design with vibrant colors, unique openwork design, and clear logos and model displays, redefining traditional crimping machines and pioneering a new fashion trend.
Hose-Crimper specification
| Crimp head material | High strength forge steel © "German Industry 4.0" |
| Crimping Diameter Range | 10mm-87mm (*Special sizes can be customized) |
| Capacity of Crimper | 1. Standard Crimper Size:14mm-75mm (*Four steel wires sprial 4SH 2”) 2. Use a Additional purchase of Die Size:10mm-87mm (*Six steel wires sprial R15 2”) |
| Max Opening | 33 mm |
| Max opening without dies | 33 mm + 99 mm = 132 mm |
| Pump flow rate | 12 L/min |
| Max Pressure | 275 bar |
| Crimping Force | 2000 kN |
| Motor power | 4000 W |
| Theoretical Production Capacity | 850 times per hour |
| Speed of Master Dies Closing/open | 2.7 mm/s |
| Sound Pressure Level | 71 dB(A) [Reference target: ISO 45001] |
| Oil tank volume | 55 L |
| Oil quantity/ type | 50 L Recommended : Winter: YB-N32 [HM 32] Summer: YB-N46 [HM46] |
| Enclosure Class | IP 54 |
| Weight | 260 kg (Excluding Oil) |
| Size:Length * width * height | 710 * 500 * 1350 mm |
| Foot pedal / switch | Included [Reference target: ISO 45001] |
| Number | Die No. | Crimp Range (mm) | D (mm ) | L (mm) |
|---|---|---|---|---|
| 1 | 10 | 10-12【Additional purchase】 | 10 | 55 |
| 2 | 12 | 12-14【Additional purchase】 | 12 | 55 |
| 3 | 14 | 14-16 | 14 | 55 |
| 4 | 16 | 16-19 | 16 | 55 |
| 5 | 19 | 19-22 | 19 | 55 |
| 6 | 22 | 22-26 | 22 | 70 |
| 7 | 26 | 26-30 | 26 | 70 |
| 8 | 30 | 30-34 | 30 | 70 |
| 9 | 34 | 34-39 | 34 | 75 |
| 10 | 39 | 39-45 | 39 | 75 |
| 11 | 45 | 45-51 | 45 | 90 |
| 12 | 51 | 51-57 | 51 | 90 |
| 13 | 57 | 57-63 | 57 | 100 |
| 14 | 63 | 63-69 | 63 | 110 |
| 15 | 69 | 69-75 | 69 | 110 |
| 16 | 74 | 74-80【Additional purchase】 | 74 | 110 |
| 17 | 78 | 78-87【Additional purchase】 | 78 | 110 |
Hose-Crimper Features
Novel appearance.
Operation in line with manual functional science
The patented product of mold replacement tool, 100% efficiency improvement and easy operation
Machine head adopts one piece forging parts with high strength.
17 sets of molds are provided to fit your crimping requirements. And all molds are treated through 2 times of vacuum polishing, with a high degree of finish and long service life.
